Three.js: EXR example is broken on latest Chrome with Windows

[antonbagayev]

Hi all,

This literally broke overnight - it worked all day yesterday. Update to the latest chrome and this example will be pitch black (because geometry itself is black on the black background):
https://threejs.org/examples/webgl_materials_envmaps_exr.html

The recurring error pattern in the dev console is:

[.WebGL-000001B8882DE700] GL_INVALID_FRAMEBUFFER_OPERATION: Framebuffer is incomplete.
webgl_materials_envmaps_exr.html:1 [.WebGL-000001B8882DE700] GL_INVALID_FRAMEBUFFER_OPERATION: Draw framebuffer is incomplete

If you switch to the PNG in the above example - all looks good, so it's just EXR.

HDR example works too
https://threejs.org/examples/webgl_materials_envmaps_hdr.html
so it's an issue for just EXR one.

Three.js version

• [ ] Dev
• [x] r102, but is also reproducible on at least r98
• [ ] ...

Browser

• [x] Chrome
• [ ] Firefox
• [ ] Internet Explorer

OS

• [] All of them
• [x] Windows
• [ ] macOS
• [ ] Linux
• [ ] Android
• [ ] iOS

NOTE: this seems to be a Windows-only issue, as the latest Chrome on iOS works.

This may be related to https://github.com/mrdoob/three.js/issues/15343

[Mugen87]

NOTE: this seems to be a Windows-only issue, as the latest Chrome on iOS works.

True. I'm unable to reproduce on macOS with Chrome 73.0.3683.75.

[Mugen87]

Can you please check out if the workaround shared by @silvainSayduck does help?

https://github.com/mrdoob/three.js/issues/15343#issuecomment-457528822

[antonbagayev]

What seems to work for us is changing the type in line
let cubemapGenerator = new THREE.EquirectangularToCubeGenerator(texture, { resolution: 512, type: THREE.HalfFloatType });
from
THREE.HalfFloatType to THREE.FloatType

EXR lighting does look a bit different on r102 for same EXRs with the above change, but it's still better than black models.

[antonbagayev]

Just tried the workaround suggested by @silvainSayduck - kept getting this error:

MYC3D.js:1639 Uncaught DOMException: Failed to construct 'ImageData': The input data length is not equal to (4 * width * height).

for the line:

const imageData = new ImageData(new Uint8ClampedArray(dataTexture.image.data.map((value) => value * 255)), dataTexture.image.width, dataTexture.image.height);

Apparently constructing ImageData requires dataTexture.image.data to be equal to 4 * width * height?

[Mugen87]

Um, the original type of the loaded EXR texture is THREE.FloatType. THREE.CubemapGenerator respects the original type of the texture whereas THREE.EquirectangularToCubeGenerator allows to overwrite it (e.g. with THREE.HalfFloatType).

@WestLangley Does it makes sense to provide this flexibility? Maybe it's best to switch to THREE.CubemapGenerator in this example...

[mrdoob]

Chrome 73/Windows regression:
https://twitter.com/BenHouston3D/status/1105923857699889152

[antonbagayev]

They are working on it :)
https://bugs.chromium.org/p/chromium/issues/detail?id=941671#c9

[silvainSayduck]

Just tried the workaround suggested by @silvainSayduck - kept getting this error:

MYC3D.js:1639 Uncaught DOMException: Failed to construct 'ImageData': The input data length is not equal to (4 * width * height).

for the line:

const imageData = new ImageData(new Uint8ClampedArray(dataTexture.image.data.map((value) => value * 255)), dataTexture.image.width, dataTexture.image.height);

Apparently constructing ImageData requires dataTexture.image.data to be equal to 4 * width * height?

I noticed that this happened for some EXR files on my end too. It's when they are in RGB format. ImageData expects data to be RGBA. Here's the updated workaround:

const originalData = dataTexture.image.data;
const imageWidth = dataTexture.image.width;
const imageHeight = dataTexture.image.height;
let data;
if (originalData.length === imageHeight * imageWidth * 3) {
  // RGB format, need to insert 255 values for alpha channel
  data = new Float32Array(4 * imageWidth * imageHeight);
  data.fill(255);
  originalData.forEach((value, ix) => {
    const destinationIndex = ix + Math.floor(ix / 3);
    data.fill(value * 255, destinationIndex, destinationIndex + 1);
  });
} else {
  data = originalData.map(value => value * 255);
}
const imageData = new ImageData(
  new Uint8ClampedArray(data),
  imageWidth,
  imageHeight
);
texture = new THREE.Texture(imageData);
texture.needsUpdate = true;

[mrdoob]

I think you should be able to just do texture.format = THREE.RGBAFormat;.

[silvainSayduck]

Thanks for jumping in! However, I'm not sure I understand on which texture this should be applied?

To recreate the Texture that works on Android, I need to create the ImageData, and that expects a Float32Array of length imageWidth * imageHeight * 4. The data in originalData is of length imageWidth * imageHeight * 3 if the EXR file is RGB.

Do you mean that applying dataTexture.format = THREE.RGBAFormat would somehow update dataTexture.image.data? Or that by setting dataTexture.format = THREE.RGBAFormat, the dataTexture would then work directly on Android without having to recreate a Texture at all?

Because from what I understand, it seems that you're saying to apply texture.format = THREE.RGBAFormat on the final texture (two last lines of my snippet). But that Texture can't even be created without the new Float32Array...

[mrdoob]

Chrome 74 is out. Has this been fixed?

[antonbagayev]

Yes, this is now fixed and can be closed.
Thanks everyone.
