Botbuilder-samples: Failed to acquire token for client credentials.

[LindaLawton]

I am currently following Teams Conversation Bot sample. I have followed it to the letter as far as i can see.

What works.

When i talk to the bot though the web view

I can see it hitting the code on my localhost.

 protected override async Task OnMessageActivityAsync(ITurnContext<IMessageActivity> turnContext, CancellationToken cancellationToken)
        {
            turnContext.Activity.RemoveRecipientMention();

            switch (turnContext.Activity.Text.Trim())
            {
                case "MentionMe":
                    await MentionActivityAsync(turnContext, cancellationToken);
                    break;

                case "UpdateCardAction":
                    await UpdateCardActivityAsync(turnContext, cancellationToken);
                    break;

                case "Delete":
                    await DeleteCardActivityAsync(turnContext, cancellationToken);
                    break;

                case "MessageAllMembers":
                    await MessageAllMembersAsync(turnContext, cancellationToken);
                    break;

                default:
                    var value = new JObject { { "count", 0 } };

                    var card = new HeroCard
                    {
                        Title = "Welcome Card",
                        Text = "Click the buttons below to update this card",
                        Buttons = new List<CardAction>
                        {
                            new CardAction
                            {
                                Type= ActionTypes.MessageBack,
                                Title = "Update Card",
                                Text = "UpdateCardAction",
                                Value = value
                            },
                            new CardAction
                            {
                                Type = ActionTypes.MessageBack,
                                Title = "Message all members",
                                Text = "MessageAllMembers"
                            }
                        }
                    };

                    await turnContext.SendActivityAsync(MessageFactory.Attachment(card.ToAttachment()));
                    break;
            }
        }

what doesn't work

It appears to send the response back but nothing appears in the response window. How do i test this if it doesn't show the response?

Ngrok error

After a bit more digging I can see that ngrok is getting an error back of sorts its a web page I managed to pick the following error out of it.

AggregateException: Failed to acquire token for client credentials. (AADSTS700016: Application with identifier '9e0d71-7665-4f24-8898-f82f9bebba56' was not found in the directory 'botframework.com'. This can happen if the application has not been installed by the administrator of the tenant or consented to by any user in the tenant. You may have sent your authentication request to the wrong tenant.

Trace ID: 4bf53bae-84dc-4b16-98e8-e99b322dc200

Correlation ID: 3c249469-d177-49dd-989f-80044a3b9faa

Timestamp: 2019-11-12 08:41:56Z) (AADSTS700016: Application with identifier 'e0d71-7665-4f24-8898-f82f9bebba56' was not found in the directory 'botframework.com'. This can happen if the application has not been installed by the administrator of the tenant or consented to by any user in the tenant. You may have sent your authentication request to the wrong tenant.

I have checked the settings on the bot and the application itself. They have the same secret and application client id.

botframework.com appears to contain a list of bots that were created on azure.

What i have tried.

• Visual studio is running as administrator.

• Chckedbotframework.com my bot is listed.

• Users have the write to create apps in AD, I am currently the only user anyway.

web chat errors

I can see in the bot that its logging errors with the web chat

The thing is the bot is responding.

Emulator

Running the emulator does work. The issue appears to be with the setup of the bot on azure.

Cross posted here https://stackoverflow.com/q/58814879/1841839

[jwiley84]

It looks like something might have gone sideways when you registered your bot on Azure. Can I get your bot channel registration's app ID?

[LindaLawton]

Sure thing 829e0d71-7665-4f24-8898-f82f9bebba56 I have tried recreating the bot a few times. I also tried with echo bot there is no change that one can call the code from azure web chat but the response never makes it back to the web chat.

I have considered deploying it but I am not sure how thats going to work when the settings are read from env vars in azure but these samples appear to only read from app.settings json.

[jwiley84]

Looking into this.

[LindaLawton]

I went ahead and enabled logging in the bot and pushed it up to Azure. I am seeing the same error there

Trace ID: 7d65b26f-b461-4906-803f-b637cad53401
Correlation ID: 9fe70397-dbf6-4bde-a361-b19abf7f090f
Timestamp: 2019-11-14 14:39:50Z) (AADSTS700016: Application with identifier '829e0d71-7665-4f24-8898-f82f9bebba56' was not found in the directory 'botframework.com'. This can happen if the applica
tion has not been installed by the administrator of the tenant or consented to by any user in the tenant. You may have sent your authentication request to the wrong tenant.
Trace ID: 7d65b26f-b461-4906-803f-b637d2d53401

Any info on this would be great because i was due to show this to some people on Friday as a proof of concept. Is this something i am doing wrong or is it an issue on Azures end?

[jwiley84]

because you're running this in localhost, let's check your appsettings.json. Have you updated it with your MicrosoftAppId and AppPassword?

{
  "MicrosoftAppId": "829e0d71-7665-4f24-8898-f82f9bebba56",
  "MicrosoftAppPassword": "tu0<rest of your password here>"
}

[LindaLawton]

Yes as all of the settings have been added to the app.settings json file. if they were not there then Azure would not be responding with the App id i sent which is in the error message

Application with identifier '829e0d71-7665-4f24-8898-f82f9bebba56' was not found in the directory 'botframework.com'.

As menonted in my last message i suspected it may have something to do with localhost so I published it to Azure. It is also configured properly and returns the same error message. 829e0d71-7665-4f24-8898-f82f9bebba56 can not be found.

[jwiley84]

When you say you published to azure, do you mean you published the whole bot? Like I said earlier, I think something went wrong when you published.

I'm not normally a fan of the "turn it off and back on again" method, but in this case, I recommend you redeploy in a fresh deployment.

[LindaLawton]

Visual studio publish to azure. Then set the azure endpoint of the bot to the endpoint of the bot.

Yes all the parameters have been added as needed

[jwiley84]

What happens if you do the same type of deployment with a standard (non-teams bot)?

[LindaLawton]

No idea TBH I am doing this by following your tutorials.

Btw doing it through the cli works creating everything through the azure website fails. Might give you an idea how to test this

[jwiley84]

I'm waiting for a response to an email, but can you try something for me? In your Azure Active Directory (in your Azure portal), can you check your settings to see if you can register apps? It's possible that your app was deployed correctly, in that it's in Azure, but not registered, so it's not actually functioning, just sitting there:

[LindaLawton]

Sorry i cant help anymore this project was done for a client I am now out of azure time on my free account. I dont think i can spinn anything up anymore.

[jwiley84]

I'm sorry we weren't able to resolve what was going on with your bot. If you need further assistance on this matter, please feel free to reopen this issue.

[carlosromero68]

@jwiley84 - I'm having the exact problem. Can we reopen this issue?

[HatBeardZero]

@carlosromero68 idk if you still need it but i had what looks like this problem and i had to change the manifest. http://thewindowsupdate.com/2019/08/19/how-to-create-an-app-registration-in-azure-ad-for-a-bot-solution/

[LindaLawton]

Solution to this was that you can not create it though the UI you need to do it all though the CLI. Something in the UI must be broken that it does not properly create things in the backend as soon as you do it though the CLI it all worked.

[ganeshglitz]

Hi,

I am getting same error as started this thread. I have followed all the troubleshooting as mentioned above, but still issue is not resolved.

could you please check this. Details are below:

I am trying to debug the simple bot in visual code using node.js with ngrok.

I am able to debug successfully without any in bot emulator. but when I am trying to debug using Teams, i am getting the following error message in visual code terminal.

POST /api/messages 401 88 - 3.377 ms
(node:9700) UnhandledPromiseRejectionWarning: Error: BotFrameworkAdapter.processActivity(): 401 ERROR
Error: Unauthorized. Invalid AppId passed on token: 5c629fa6-0ffa-4336-a404-8826971a490d
at D:\Projects\BAIN\Source Code\POC\BAIN-BOT\node_modules\botframework-connectorlib\auth\channelValidation.js:92:23
at Generator.next ()
at fulfilled (D:\Projects\BAIN\Source Code\POC\BAIN-BOT\node_modules\botframework-connectorlib\auth\channelValidation.js:4:58)
at process._tickCallback (internal/process/next_tick.js:68:7)
at BotFrameworkAdapter. (D:\Projects\BAIN\Source Code\POC\BAIN-BOT\node_modules\botbuilderlib\botFrameworkAdapter.js:674:27)
at Generator.throw ()
at rejected (D:\Projects\BAIN\Source Code\POC\BAIN-BOT\node_modules\botbuilderlib\botFrameworkAdapter.js:12:65)
at process._tickCallback (internal/process/next_tick.js:68:7)
(node:9700) UnhandledPromiseRejectionWarning: Unhandled promise rejection. This error originated either by throwing inside of an async function without a catch block, or by rejecting a promise which was not handled with .catch(). (rejection id: 7)

Application Insights Logs: - Microsoft.IdentityModel.Clients.ActiveDirectory.AdalServiceException:
Failed to acquire token for client credentials. (AADSTS700016: Application with identifier '5c629fa6-0ffa-4336-a404-8826971a490d' was not found in the directory 'botframework.com'. This can happen if the application has not been installed by the administrator of the tenant or consented to by any user in the tenant. You may have sent your authentication request to the wrong tenant.
Trace ID: 53a75490-0502-4f73-988a-1563c4a24600
Correlation ID: 6c95cea2-58c2-4e53-b5e2-661c1e5bbfd9
Timestamp: 2021-01-01 11:44:28Z

[LindaLawton]

When you set up the bot do it though the CLI dont try to do it though the web interface. Thats how i got it working.

[libindavis]

Hi,

I am getting same error as started this thread. I have followed all the troubleshooting as mentioned above, but still issue is not resolved.

could you please check this. Details are below:

I am trying to debug the simple bot in visual code using node.js with ngrok.

I am able to debug successfully without any in bot emulator. but when I am trying to debug using Teams, i am getting the following error message in visual code terminal.

POST /api/messages 401 88 - 3.377 ms
(node:9700) UnhandledPromiseRejectionWarning: Error: BotFrameworkAdapter.processActivity(): 401 ERROR
Error: Unauthorized. Invalid AppId passed on token: 5c629fa6-0ffa-4336-a404-8826971a490d
at D:\Projects\BAIN\Source Code\POC\BAIN-BOT\node_modules\botframework-connectorlib\auth\channelValidation.js:92:23
at Generator.next ()
at fulfilled (D:\Projects\BAIN\Source Code\POC\BAIN-BOT\node_modules\botframework-connectorlib\auth\channelValidation.js:4:58)
at process._tickCallback (internal/process/next_tick.js:68:7)
at BotFrameworkAdapter. (D:\Projects\BAIN\Source Code\POC\BAIN-BOT\node_modules\botbuilderlib\botFrameworkAdapter.js:674:27)
at Generator.throw ()
at rejected (D:\Projects\BAIN\Source Code\POC\BAIN-BOT\node_modules\botbuilderlib\botFrameworkAdapter.js:12:65)
at process._tickCallback (internal/process/next_tick.js:68:7)
(node:9700) UnhandledPromiseRejectionWarning: Unhandled promise rejection. This error originated either by throwing inside of an async function without a catch block, or by rejecting a promise which was not handled with .catch(). (rejection id: 7)

Application Insights Logs: - Microsoft.IdentityModel.Clients.ActiveDirectory.AdalServiceException:
Failed to acquire token for client credentials. (AADSTS700016: Application with identifier '5c629fa6-0ffa-4336-a404-8826971a490d' was not found in the directory 'botframework.com'. This can happen if the application has not been installed by the administrator of the tenant or consented to by any user in the tenant. You may have sent your authentication request to the wrong tenant.
Trace ID: 53a75490-0502-4f73-988a-1563c4a24600
Correlation ID: 6c95cea2-58c2-4e53-b5e2-661c1e5bbfd9
Timestamp: 2021-01-01 11:44:28Z

I've encountered the same issue, here is how I resolve it.

1. go to your bot in the Azure portal
2. select the 'Authentication' menu on the left panel
3. select 'Accounts in any organizational directory (Any Azure AD directory - Multitenant)' in the 'Supported account types' as below
