Xrdp: Black screen - Closed socket 19 (AF_UNIX) error
Installing from source, I get these errors and black screen:
Jun 24 01:58:34 server1 xrdp[27779]: (27779)(140475567515392)[DEBUG] Closed socket 19 (AF_UNIX)
Jun 24 01:58:38 server1 xrdp[27779]: (27779)(140475567515392)[DEBUG] Closed socket 19 (AF_UNIX)
Jun 24 01:58:41 server1 xrdp[27779]: (27779)(140475567515392)[DEBUG] Closed socket 19 (AF_UNIX)
Jun 24 01:58:45 server1 xrdp[27779]: (27779)(140475567515392)[DEBUG] Closed socket 19 (AF_UNIX)
Jun 24 01:58:48 server1 xrdp[27779]: (27779)(140475567515392)[DEBUG] Closed socket 19 (AF_UNIX)
Jun 24 01:58:52 server1 xrdp[27779]: (27779)(140475567515392)[DEBUG] Closed socket 19 (AF_UNIX)
Any idea what could be causing?
johnarnold
All 63 comments
Stay the blank screen, timeout will occur and maybe you'll see some messages in dialog.
metalefty
on 25 Jun 2017
Isn't your issue /etc/X11/Xwrapper.config written in README.Debian?
https://anonscm.debian.org/cgit/pkg-remote/xrdp.git/tree/debian/README.Debian
metalefty
on 25 Jun 2017
I have seen this if the virtual channels sockets are correctly set up.
geiseri
on 28 Jun 2017
Isn't it the same as described in #764?
tfischer77
on 1 Jul 2017
@metalefty
I tried installing xserver-xorg-legacy and it broke a bunch of stuff and I ended up removing it. This on Ubuntu 16.04
/etc/X11/Xwrapper.config doesn't exist (without X11-common or some other package?)
johnar@nethop1-eastus2:/var/log$ ls -l /etc/X11
total 68
drwxr-xr-x 2 root root 4096 Nov 10 2016 app-defaults
drwxr-xr-x 3 root root 4096 Nov 9 2016 fonts
-rw-r--r-- 1 root root 17394 Nov 10 2015 rgb.txt
drwxr-xr-x 3 root root 4096 Feb 10 03:22 xinit
drwxr-xr-x 2 root root 4096 Jan 22 2016 xkb
drwxr-xr-x 2 root root 4096 Jul 14 15:13 xrdp
-rwxr-xr-x 1 root root 709 Nov 10 2015 Xreset
drwxr-xr-x 2 root root 4096 Oct 21 2016 Xreset.d
drwxr-xr-x 2 root root 4096 Oct 21 2016 Xresources
-rwxr-xr-x 1 root root 3730 Mar 4 2016 Xsession
drwxr-xr-x 2 root root 4096 May 18 06:37 Xsession.d
-rw-r--r-- 1 root root 265 Nov 10 2015 Xsession.options
drwxr-xr-x 2 root root 4096 Nov 9 2016 xsm
I'm not sure about Debian and Xwrapper.config doesn't exist for me, too.
Creating it and set allowed_users=anybody worked for me.
metalefty
on 15 Jul 2017
@metalefty I created the file, with allowed_users=anybody still get black screen.
/var/log/xrdp.log:
[20170717-16:54:34] [INFO ] connected client computer name: SAW-L6515306ZPO
[20170717-16:54:34] [INFO ] TLS connection established from 10.64.3.54 port 57508: TLSv1.2 with cipher AES256-GCM-SHA384
[20170717-16:54:35] [DEBUG] xrdp_0000ed2a_wm_login_mode_event_00000001
[20170717-16:54:35] [INFO ] Loading keymap file /etc/xrdp/km-00000409.ini
[20170717-16:54:35] [WARN ] local keymap file for 0x00000409 found and doesn't match built in keymap, using local keymap file
[20170717-16:54:35] [DEBUG] xrdp_wm_log_msg: connecting to sesman ip 127.0.0.1 port 3350
[20170717-16:54:35] [INFO ] xrdp_wm_log_msg: sesman connect ok
[20170717-16:54:36] [DEBUG] xrdp_wm_log_msg: sending login info to session manager, please wait...
[20170717-16:54:36] [DEBUG] return value from xrdp_mm_connect 0
[20170717-16:54:36] [INFO ] xrdp_wm_log_msg: login successful for display 12
[20170717-16:54:36] [DEBUG] xrdp_wm_log_msg: started connecting
[20170717-16:54:37] [DEBUG] Closed socket 25 (AF_UNIX)
[20170717-16:54:39] [DEBUG] Closed socket 19 (AF_UNIX)
[20170717-16:54:40] [DEBUG] xrdp_wm_log_msg: connection problem, giving up
[20170717-16:54:40] [DEBUG] Closed socket 25 (AF_UNIX)
[20170717-16:54:40] [DEBUG] xrdp_wm_log_msg: some problem
[20170717-16:54:40] [DEBUG] xrdp_mm_module_cleanup
[20170717-16:54:40] [DEBUG] Closed socket 24 (AF_INET 127.0.0.1:40790)
[20170717-16:54:43] [DEBUG] Closed socket 19 (AF_UNIX)
[20170717-16:54:47] [DEBUG] Closed socket 19 (AF_UNIX)
[20170717-16:54:50] [DEBUG] Closed socket 19 (AF_UNIX)
[20170717-16:54:54] [DEBUG] Closed socket 19 (AF_UNIX)
[20170717-16:54:57] [DEBUG] Closed socket 19 (AF_UNIX)
/var/log/xrdp-sesman.log:
[20170717-16:54:35] [INFO ] A connection received from 127.0.0.1 port 55408
[20170717-16:54:36] [INFO ] ++ created session (access granted): username johnar, ip 10.64.3.54:57508 - socket: 12
[20170717-16:54:36] [INFO ] starting Xorg session...
[20170717-16:54:36] [DEBUG] Closed socket 9 (AF_INET 0.0.0.0:5910)
[20170717-16:54:36] [DEBUG] Closed socket 9 (AF_INET 0.0.0.0:6010)
[20170717-16:54:36] [DEBUG] Closed socket 9 (AF_INET 0.0.0.0:6210)
[20170717-16:54:36] [DEBUG] Closed socket 9 (AF_INET 0.0.0.0:5911)
[20170717-16:54:36] [DEBUG] Closed socket 9 (AF_INET 0.0.0.0:6011)
[20170717-16:54:36] [DEBUG] Closed socket 9 (AF_INET 0.0.0.0:6211)
[20170717-16:54:36] [DEBUG] Closed socket 9 (AF_INET 0.0.0.0:5912)
[20170717-16:54:36] [DEBUG] Closed socket 9 (AF_INET 0.0.0.0:6012)
[20170717-16:54:36] [DEBUG] Closed socket 9 (AF_INET 0.0.0.0:6212)
[20170717-16:54:36] [DEBUG] Closed socket 8 (AF_INET 127.0.0.1:3350)
[20170717-16:54:36] [INFO ] calling auth_start_session from pid 60715
[20170717-16:54:36] [DEBUG] Closed socket 7 (AF_INET 127.0.0.1:3350)
[20170717-16:54:36] [DEBUG] Closed socket 8 (AF_INET 127.0.0.1:3350)
[20170717-16:54:36] [INFO ] Xorg :12 -auth .Xauthority -config xrdp/xorg.conf -noreset -nolisten tcp -logfile .xorgxrdp.%s.log
[20170717-16:54:36] [CORE ] waiting for window manager (pid 60717) to exit
[20170717-16:54:36] [CORE ] window manager (pid 60717) did exit, cleaning up session
[20170717-16:54:36] [INFO ] calling auth_stop_session and auth_end from pid 60715
[20170717-16:54:36] [INFO ] ++ terminated session: username johnar, display :12.0, session_pid 60715, ip 10.64.3.54:57508 - socket: 12
Which desktop environment do you use?
On Mon, Jul 17, 2017 at 8:10 PM John Arnold notifications@github.com
wrote:
@metalefty https://github.com/metalefty I created the file, with
allowed_users=anybody still get black screen./var/log/xrdp.log:
[20170717-16:54:34] [INFO ] connected client computer name: SAW-L6515306ZPO
[20170717-16:54:34] [INFO ] TLS connection established from 10.64.3.54 port 57508: TLSv1.2 with cipher AES256-GCM-SHA384
[20170717-16:54:35] [DEBUG] xrdp_0000ed2a_wm_login_mode_event_00000001
[20170717-16:54:35] [INFO ] Loading keymap file /etc/xrdp/km-00000409.ini
[20170717-16:54:35] [WARN ] local keymap file for 0x00000409 found and doesn't match built in keymap, using local keymap file
[20170717-16:54:35] [DEBUG] xrdp_wm_log_msg: connecting to sesman ip 127.0.0.1 port 3350
[20170717-16:54:35] [INFO ] xrdp_wm_log_msg: sesman connect ok
[20170717-16:54:36] [DEBUG] xrdp_wm_log_msg: sending login info to session manager, please wait...
[20170717-16:54:36] [DEBUG] return value from xrdp_mm_connect 0
[20170717-16:54:36] [INFO ] xrdp_wm_log_msg: login successful for display 12
[20170717-16:54:36] [DEBUG] xrdp_wm_log_msg: started connecting
[20170717-16:54:37] [DEBUG] Closed socket 25 (AF_UNIX)
[20170717-16:54:39] [DEBUG] Closed socket 19 (AF_UNIX)
[20170717-16:54:40] [DEBUG] xrdp_wm_log_msg: connection problem, giving up
[20170717-16:54:40] [DEBUG] Closed socket 25 (AF_UNIX)
[20170717-16:54:40] [DEBUG] xrdp_wm_log_msg: some problem
[20170717-16:54:40] [DEBUG] xrdp_mm_module_cleanup
[20170717-16:54:40] [DEBUG] Closed socket 24 (AF_INET 127.0.0.1:40790)
[20170717-16:54:43] [DEBUG] Closed socket 19 (AF_UNIX)
[20170717-16:54:47] [DEBUG] Closed socket 19 (AF_UNIX)
[20170717-16:54:50] [DEBUG] Closed socket 19 (AF_UNIX)
[20170717-16:54:54] [DEBUG] Closed socket 19 (AF_UNIX)
[20170717-16:54:57] [DEBUG] Closed socket 19 (AF_UNIX)/var/log/xrdp-sesman.log:
[20170717-16:54:35] [INFO ] A connection received from 127.0.0.1 port 55408
[20170717-16:54:36] [INFO ] ++ created session (access granted): username johnar, ip 10.64.3.54:57508 - socket: 12
[20170717-16:54:36] [INFO ] starting Xorg session...
[20170717-16:54:36] [DEBUG] Closed socket 9 (AF_INET 0.0.0.0:5910)
[20170717-16:54:36] [DEBUG] Closed socket 9 (AF_INET 0.0.0.0:6010)
[20170717-16:54:36] [DEBUG] Closed socket 9 (AF_INET 0.0.0.0:6210)
[20170717-16:54:36] [DEBUG] Closed socket 9 (AF_INET 0.0.0.0:5911)
[20170717-16:54:36] [DEBUG] Closed socket 9 (AF_INET 0.0.0.0:6011)
[20170717-16:54:36] [DEBUG] Closed socket 9 (AF_INET 0.0.0.0:6211)
[20170717-16:54:36] [DEBUG] Closed socket 9 (AF_INET 0.0.0.0:5912)
[20170717-16:54:36] [DEBUG] Closed socket 9 (AF_INET 0.0.0.0:6012)
[20170717-16:54:36] [DEBUG] Closed socket 9 (AF_INET 0.0.0.0:6212)
[20170717-16:54:36] [DEBUG] Closed socket 8 (AF_INET 127.0.0.1:3350)
[20170717-16:54:36] [INFO ] calling auth_start_session from pid 60715
[20170717-16:54:36] [DEBUG] Closed socket 7 (AF_INET 127.0.0.1:3350)
[20170717-16:54:36] [DEBUG] Closed socket 8 (AF_INET 127.0.0.1:3350)
[20170717-16:54:36] [INFO ] Xorg :12 -auth .Xauthority -config xrdp/xorg.conf -noreset -nolisten tcp -logfile .xorgxrdp.%s.log
[20170717-16:54:36] [CORE ] waiting for window manager (pid 60717) to exit
[20170717-16:54:36] [CORE ] window manager (pid 60717) did exit, cleaning up session
[20170717-16:54:36] [INFO ] calling auth_stop_session and auth_end from pid 60715
[20170717-16:54:36] [INFO ] ++ terminated session: username johnar, display :12.0, session_pid 60715, ip 10.64.3.54:57508 - socket: 12—
You are receiving this because you are subscribed to this thread.
Reply to this email directly, view it on GitHub
https://github.com/neutrinolabs/xrdp/issues/786#issuecomment-315817179,
or mute the thread
https://github.com/notifications/unsubscribe-auth/ADTH1GWXrogOQScxB-TRWZ7rl9aSxztpks5sO5TBgaJpZM4OEMBO
.>
Idan Freiberg
PGP FP: 8108 7EC9 806E 4980 75F2 72B3 8AD3 2D04 337B 1F18
speidy
on 17 Jul 2017
Ok, so this is weird to me. If I move the window manager launch (mate-session, in my case) to the top of the wm_start() function in /etc/xrdp/startwm.sh, it launches ok:
#start the window manager
wm_start()
{
mate-session
if [ -r /etc/default/locale ]; then
. /etc/default/locale
export LANG LANGUAGE
fi
# debian
if [ -r /etc/X11/Xsession ]; then
pre_start
# mate-session
# . /etc/X11/Xsession
post_start
exit 0
fi
However, if it's after the locale check and after pre_start function (e.g. where Xsession would normally launch) -- I get the black screen and the AF_UNIX errors.
Ideas? Shouldn't mate-session be after pre_start, where Xsession would otherwise launch?
johnarnold
on 17 Jul 2017
Did you check if you got the Xsession file in place?
On Mon, Jul 17, 2017 at 8:28 PM John Arnold notifications@github.com
wrote:
Ok, so this is weird to me. If I move the window manager launch
(mate-session, in my case) to the top of the wm_start() function in
/etc/xrdp/startwm.sh, it launches ok:start the window manager
wm_start()
{
mate-sessionif [ -r /etc/default/locale ]; then
. /etc/default/locale
export LANG LANGUAGE
fi# debian
if [ -r /etc/X11/Xsession ]; then
pre_startmate-session
. /etc/X11/Xsession
post_start exit 0fi
However, if it's after the locale check and after pre_start function (e.g.
where Xsession would normally launch) -- I get the black screen and the
AF_UNIX errors.Ideas? Shouldn't mate-session be after pre_start, where Xsession would
otherwise launch?—
You are receiving this because you commented.Reply to this email directly, view it on GitHub
https://github.com/neutrinolabs/xrdp/issues/786#issuecomment-315823423,
or mute the thread
https://github.com/notifications/unsubscribe-auth/ADTH1PLXvyapJdDFe7hKl7EihFiTpJy0ks5sO5nLgaJpZM4OEMBO
.>
Idan Freiberg
PGP FP: 8108 7EC9 806E 4980 75F2 72B3 8AD3 2D04 337B 1F18
speidy
on 17 Jul 2017
@speidy Yes, I checked both the test statements.
johnar@nethop1-eastus2:~$ ./start.sh
found locale
found Xsession
johnar@nethop1-eastus2:~$ cat start.sh
if [ -r /etc/default/locale ]; then
#. /etc/default/locale
echo "found locale"
#export LANG LANGUAGE
fi
if [ -r /etc/X11/Xsession ]; then
echo "found Xsession"
# pre_start
# mate-session
# . /etc/X11/Xsession
# post_start
exit 0
fi
johnar@nethop1-eastus2:~$ ls -lrt /etc/X11/Xsession
-rwxr-xr-x 1 root root 3730 Mar 4 2016 /etc/X11/Xsession
@johnarnold Check my last post (MATE related) here #765 What xrdp session type are you using for connection? Because Xorg session working fine for me on Ubuntu 16.04...
xorgxrdp 0.2.2-0ubuntu1
xrdp 0.9.2-0ubuntu1
grishin-a
on 19 Jul 2017
I too have this issue.
Archlinux on both sides. Spent the better part of the day trying to learn the ins and outs of xrdp.
Following the debian instructions does not help, although I couldn't test xorg-server-legacy because that doesn't seem to exist for Arch.
AeliusSaionji
on 3 Aug 2017
@metalefty you've posted in multiple issues that setting Xsession to allowed_users=anybody is the fix, but it's not a fix, at least not for Ubuntu 16.04 (and prob others).
Built off latest source:
johnar@netdev1-westus2:~$ cat /etc/X11/Xwrapper.config
allowed_users=anybody
johnar@netdev1-westus2:~$ xrdp --version
xrdp: A Remote Desktop Protocol server.
Copyright (C) Jay Sorg 2004-2014
See http://www.xrdp.org for more information.
Version 0.9.3
/var/log/xrdp.log:
[20170804-01:50:17] [INFO ] Socket 12: AF_INET connection received from 10.64.3.54 port 31863
[20170804-01:50:17] [DEBUG] Closed socket 12 (AF_INET 10.20.0.101:3389)
[20170804-01:50:17] [DEBUG] Closed socket 11 (AF_INET 0.0.0.0:3389)
[20170804-01:50:17] [INFO ] Using default X.509 certificate: /etc/xrdp/cert.pem
[20170804-01:50:17] [INFO ] Using default X.509 key file: /etc/xrdp/key.pem
[20170804-01:50:17] [DEBUG] TLSv1.2 enabled
[20170804-01:50:17] [DEBUG] TLSv1.1 enabled
[20170804-01:50:17] [DEBUG] TLSv1 enabled
[20170804-01:50:17] [DEBUG] Security layer: requested 11, selected 1
[20170804-01:50:17] [INFO ] connected client computer name: SAW-L6515306ZPO
[20170804-01:50:19] [INFO ] TLS connection established from 10.64.3.54 port 31863: TLSv1.2 with cipher AES256-GCM-SHA384
[20170804-01:50:19] [DEBUG] xrdp_00000816_wm_login_mode_event_00000001
[20170804-01:50:19] [INFO ] Loading keymap file /etc/xrdp/km-00000409.ini
[20170804-01:50:19] [WARN ] local keymap file for 0x00000409 found and doesn't match built in keymap, using local keymap file
[20170804-01:50:19] [DEBUG] xrdp_wm_log_msg: connecting to sesman ip 127.0.0.1 port 3350
[20170804-01:50:20] [INFO ] xrdp_wm_log_msg: sesman connect ok
[20170804-01:50:20] [DEBUG] xrdp_wm_log_msg: sending login info to session manager, please wait...
[20170804-01:50:20] [DEBUG] return value from xrdp_mm_connect 0
[20170804-01:50:20] [INFO ] xrdp_wm_log_msg: login successful for display 10
[20170804-01:50:20] [DEBUG] xrdp_wm_log_msg: started connecting
[20170804-01:50:23] [DEBUG] Closed socket 25 (AF_UNIX)
[20170804-01:50:27] [DEBUG] Closed socket 25 (AF_UNIX)
[20170804-01:50:31] [DEBUG] Closed socket 25 (AF_UNIX)
[20170804-01:50:34] [DEBUG] Closed socket 25 (AF_UNIX)
[20170804-01:50:38] [DEBUG] Closed socket 25 (AF_UNIX)
... repeats many times
[20170804-01:53:45] [DEBUG] Closed socket 25 (AF_UNIX)
[20170804-01:53:49] [DEBUG] Closed socket 25 (AF_UNIX)
[20170804-01:53:52] [DEBUG] xrdp_wm_log_msg: connection problem, giving up
[20170804-01:53:52] [DEBUG] Closed socket 25 (AF_UNIX)
[20170804-01:53:52] [DEBUG] xrdp_wm_log_msg: some problem
[20170804-01:53:52] [DEBUG] xrdp_mm_module_cleanup
[20170804-01:53:52] [DEBUG] Closed socket 24 (AF_INET 127.0.0.1:37296)
/var/log/xrdp-sesman.log:
[20170804-01:48:21] [INFO ] starting xrdp-sesman with pid 1396
[20170804-01:48:21] [INFO ] listening to port 3350 on 127.0.0.1
[20170804-01:50:19] [INFO ] A connection received from 127.0.0.1 port 37296
[20170804-01:50:20] [INFO ] ++ created session (access granted): username johnar, ip 10.64.3.54:31863 - socket: 12
[20170804-01:50:20] [INFO ] starting Xorg session...
[20170804-01:50:20] [DEBUG] Closed socket 9 (AF_INET 0.0.0.0:5910)
[20170804-01:50:20] [DEBUG] Closed socket 9 (AF_INET 0.0.0.0:6010)
[20170804-01:50:20] [DEBUG] Closed socket 9 (AF_INET 0.0.0.0:6210)
[20170804-01:50:20] [DEBUG] Closed socket 8 (AF_INET 127.0.0.1:3350)
[20170804-01:50:20] [INFO ] calling auth_start_session from pid 2072
[20170804-01:50:20] [DEBUG] Closed socket 7 (AF_INET 127.0.0.1:3350)
[20170804-01:50:20] [DEBUG] Closed socket 8 (AF_INET 127.0.0.1:3350)
[20170804-01:50:30] [ERROR] X server for display 10 startup timeout
[20170804-01:50:30] [ERROR] X server for display 10 startup timeout
[20170804-01:50:30] [ERROR] another Xserver might already be active on display 10 - see log
[20170804-01:50:30] [CORE ] waiting for window manager (pid 2074) to exit
[20170804-01:50:30] [DEBUG] aborting connection...
[20170804-01:50:30] [CORE ] window manager (pid 2074) did exit, cleaning up session
[20170804-01:50:30] [INFO ] calling auth_stop_session and auth_end from pid 2072
[20170804-01:50:30] [INFO ] shutting down sesman 1
[20170804-01:50:30] [INFO ] ++ terminated session: username johnar, display :10.0, session_pid 2072, ip 10.64.3.54:31863 - socket: 12
[20170804-01:50:40] [INFO ] Xorg :10 -auth .Xauthority -config xrdp/xorg.conf -noreset -nolisten tcp -logfile .xorgxrdp.%s.log
Still broken. I have some servers with 0.9.2 working, some with 0.9.3 working, most are not working with either. Configs are identical (deployed via ansible). Open to suggestions on how to debug.
johnarnold
on 4 Aug 2017
@johnarnold
I don't mean that is always a fix. Just I wanted to clarify what is the real issue.
I have some different approaches depending on whether the issue is allowed_users=anybody or not.
metalefty
on 4 Aug 2017
@metalefty ok cool. I'm open to ANY ideas at this point. What's interesting is that if I wait long enough, the "login had an error" box comes up, and you go back to the blue screen with the login prompt. So it seems like either something is wrong with sesman, or when startwm.sh runs it's not launching the window manager properly.
I've tried simplifying my startwm.sh to just run mate-session and nothing else, for simplicity, and still get the same problem.
johnarnold
on 4 Aug 2017
Can you run xrdp-sesman in foreground and see the output? Current xrdp doesn't output all logs to log file but some logs are written to stdout. This is why you need to run xrdp-sesman in foreground to see what's happening. The points are:
- "is Xorg started properly?"
- "is WM staerted properly?"
You'll be able to these points by seeing foreground log.
This is the most simple example of startwm.sh. Please also try this if running only mate-session doesn't help.
#!/bin/sh
xterm
BTW, I've started to improve logging
https://github.com/neutrinolabs/xrdp/wiki/Reworking-logs
metalefty
on 4 Aug 2017
with the simple startwm.sh:
first try, running from /var/log (so it couldn't create all logfiles)
[20170804-03:02:26] [DEBUG] libscp initialized
[20170804-03:02:27] [INFO ] starting xrdp-sesman with pid 6631
[20170804-03:02:27] [INFO ] listening to port 3350 on 127.0.0.1
[20170804-03:03:13] [INFO ] A connection received from 127.0.0.1 port 57154
[20170804-03:03:13] [INFO ] ++ created session (access granted): username johnar, ip 10.64.3.54:23693 - socket: 12
[20170804-03:03:13] [INFO ] starting Xorg session...
[20170804-03:03:13] [DEBUG] Closed socket 9 (AF_INET 0.0.0.0:5910)
[20170804-03:03:13] [DEBUG] Closed socket 9 (AF_INET 0.0.0.0:6010)
[20170804-03:03:14] [DEBUG] Closed socket 9 (AF_INET 0.0.0.0:6210)
[20170804-03:03:14] [DEBUG] Closed socket 8 (AF_INET 127.0.0.1:3350)
[20170804-03:03:14] [INFO ] calling auth_start_session from pid 7017
[20170804-03:03:14] [DEBUG] Closed socket 7 (AF_INET 127.0.0.1:3350)
[20170804-03:03:14] [DEBUG] Closed socket 8 (AF_INET 127.0.0.1:3350)
[20170804-03:03:24] [ERROR] X server for display 10 startup timeout
[20170804-03:03:24] [ERROR] X server for display 10 startup timeout
[20170804-03:03:24] [ERROR] another Xserver might already be active on display 10 - see log
[20170804-03:03:24] [CORE ] waiting for window manager (pid 7018) to exit
chansrv::main: using log file [/home/johnar/.local/share/xrdp/xrdp-chansrv.0.log]
[20170804-03:03:24] [CORE ] main: app started pid 7024(0x00001b70)
[20170804-03:03:24] [DEBUG] aborting connection...
[20170804-03:03:24] [INFO ] main: DISPLAY env var set to (null)
[20170804-03:03:24] [ERROR] main: error, display is zero
[20170804-03:03:24] [CORE ] window manager (pid 7018) did exit, cleaning up session
[20170804-03:03:24] [INFO ] calling auth_stop_session and auth_end from pid 7017
[20170804-03:03:24] [INFO ] shutting down sesman 1
[20170804-03:03:24] [INFO ] ++ terminated session: username johnar, display :10.0, session_pid 7017, ip 10.64.3.54:23693 - socket: 12
xauth: timeout in locking authority file .Xauthority
[20170804-03:03:34] [INFO ] Xorg :10 -auth .Xauthority -config xrdp/xorg.conf -noreset -nolisten tcp -logfile .xorgxrdp.%s.log
(EE)
Fatal server error:
(EE) Cannot open log file ".xorgxrdp.10.log"
(EE)
(EE)
Please consult the The X.Org Foundation support
at http://wiki.x.org
for help.
(EE)
^C[20170804-03:04:15] [INFO ] shutting down sesman 1
[20170804-03:04:16] [DEBUG] Closed socket 7 (AF_INET 127.0.0.1:3350)
[20170804-03:04:16] [CORE ] shutting down log subsystem...
second try, from home directory:
[20170804-03:05:11] [DEBUG] libscp initialized
[20170804-03:05:11] [INFO ] starting xrdp-sesman with pid 7035
[20170804-03:05:11] [INFO ] listening to port 3350 on 127.0.0.1
[20170804-03:05:21] [INFO ] A connection received from 127.0.0.1 port 57672
[20170804-03:05:21] [INFO ] ++ created session (access granted): username johnar, ip 10.64.3.54:60108 - socket: 12
[20170804-03:05:21] [INFO ] starting Xorg session...
[20170804-03:05:21] [DEBUG] Closed socket 9 (AF_INET 0.0.0.0:5910)
[20170804-03:05:21] [DEBUG] Closed socket 9 (AF_INET 0.0.0.0:6010)
[20170804-03:05:21] [DEBUG] Closed socket 9 (AF_INET 0.0.0.0:6210)
[20170804-03:05:21] [DEBUG] Closed socket 8 (AF_INET 127.0.0.1:3350)
[20170804-03:05:21] [INFO ] calling auth_start_session from pid 7042
[20170804-03:05:21] [DEBUG] Closed socket 7 (AF_INET 127.0.0.1:3350)
[20170804-03:05:21] [DEBUG] Closed socket 8 (AF_INET 127.0.0.1:3350)
[20170804-03:05:21] [INFO ] Xorg :10 -auth .Xauthority -config xrdp/xorg.conf -noreset -nolisten tcp -logfile .xorgxrdp.%s.log
X.Org X Server 1.18.4
Release Date: 2016-07-19
X Protocol Version 11, Revision 0
Build Operating System: Linux 4.4.0-53-generic x86_64 Ubuntu
Current Operating System: Linux netdev1-westus2.phx.gbl 4.4.0-87-generic #110-Ubuntu SMP Tue Jul 18 12:55:35 UTC 2017 x86_64
Kernel command line: BOOT_IMAGE=/boot/vmlinuz-4.4.0-87-generic root=UUID=567ab888-a3b5-43d4-a92a-f594e8653924 ro console=tty1 console=ttyS0 earlyprintk=ttyS0 rootdelay=300
Build Date: 15 December 2016 11:49:05AM
xorg-server 2:1.18.4-1ubuntu9 (For technical support please see http://www.ubuntu.com/support)
Current version of pixman: 0.33.6
Before reporting problems, check http://wiki.x.org
to make sure that you have the latest version.
Markers: (--) probed, (**) from config file, (==) default setting,
(++) from command line, (!!) notice, (II) informational,
(WW) warning, (EE) error, (NI) not implemented, (??) unknown.
(++) Log file: ".xorgxrdp.10.log", Time: Fri Aug 4 03:05:21 2017
(==) Using system config directory "/usr/share/X11/xorg.conf.d"
(EE)
Fatal server error:
(EE) parse_vt_settings: Cannot open /dev/tty0 (Permission denied)
(EE)
(EE)
Please consult the The X.Org Foundation support
at http://wiki.x.org
for help.
(EE) Please also check the log file at ".xorgxrdp.10.log" for additional information.
(EE)
(EE) Server terminated with error (1). Closing log file.
[20170804-03:05:31] [ERROR] X server for display 10 startup timeout
[20170804-03:05:31] [CORE ] waiting for window manager (pid 7043) to exit
chansrv::main: using log file [/home/johnar/.local/share/xrdp/xrdp-chansrv.0.log]
[20170804-03:05:31] [CORE ] main: app started pid 7048(0x00001b88)
[20170804-03:05:31] [INFO ] main: DISPLAY env var set to (null)
[20170804-03:05:31] [ERROR] main: error, display is zero
[20170804-03:05:31] [ERROR] X server for display 10 startup timeout
[20170804-03:05:31] [ERROR] another Xserver might already be active on display 10 - see log
[20170804-03:05:31] [DEBUG] aborting connection...
[20170804-03:05:31] [CORE ] window manager (pid 7043) did exit, cleaning up session
[20170804-03:05:31] [INFO ] calling auth_stop_session and auth_end from pid 7042
[20170804-03:05:32] [INFO ] ++ terminated session: username johnar, display :10.0, session_pid 7042, ip 10.64.3.54:60108 - socket: 12
Third try, running as sudo (with full parameter list):
johnar@netdev1-westus2:~$ sudo xrdp-sesman -n
starting sesman in foreground...
sesman config:
ListenAddress: 127.0.0.1
ListenPort: 3350
EnableUserWindowManager: 1
UserWindowManager: startwm.sh
DefaultWindowManager: startwm.sh
AuthFilePath: disabled
Xvnc parameters:
Parameter 00 Xvnc
Parameter 01 -bs
Parameter 02 -nolisten
Parameter 03 tcp
Parameter 04 -localhost
Parameter 05 -dpi
Parameter 06 96
X11rdp parameters:
Parameter 00 X11rdp
Parameter 01 -bs
Parameter 02 -nolisten
Parameter 03 tcp
Parameter 04 -uds
XOrg parameters:
Parameter 00 Xorg
Parameter 01 -config
Parameter 02 xrdp/xorg.conf
Parameter 03 -noreset
Parameter 04 -nolisten
Parameter 05 tcp
Parameter 06 -logfile
Parameter 07 .xorgxrdp.%s.log
security configuration:
AllowRootLogin: 1
MaxLoginRetry: 4
AlwaysGroupCheck: 0
No TSUsersGroup defined
No TSAdminsGroup defined
session configuration:
MaxSessions: 50
X11DisplayOffset: 10
KillDisconnected: 0
IdleTimeLimit: 0
DisconnectedTimeLimit: 0
Policy: 0
SessionVariables parameters:
Parameter 00 PULSE_SCRIPT=/etc/xrdp/pulse/default.pa
logging configuration:
LogFile: /var/log/xrdp-sesman.log
LogLevel: 4
EnableSyslog: 1
SyslogLevel: 4
[20170804-03:08:31] [DEBUG] libscp initialized
[20170804-03:08:31] [INFO ] starting xrdp-sesman with pid 7064
[20170804-03:08:31] [INFO ] listening to port 3350 on 127.0.0.1
[20170804-03:08:47] [INFO ] A connection received from 127.0.0.1 port 58424
[20170804-03:08:48] [INFO ] ++ created session (access granted): username johnar, ip 10.64.3.54:50252 - socket: 12
[20170804-03:08:48] [INFO ] starting Xorg session...
[20170804-03:08:48] [DEBUG] Closed socket 9 (AF_INET 0.0.0.0:5910)
[20170804-03:08:48] [DEBUG] Closed socket 9 (AF_INET 0.0.0.0:6010)
[20170804-03:08:48] [DEBUG] Closed socket 9 (AF_INET 0.0.0.0:6210)
[20170804-03:08:48] [DEBUG] Closed socket 8 (AF_INET 127.0.0.1:3350)
[20170804-03:08:48] [INFO ] calling auth_start_session from pid 7068
[20170804-03:08:48] [DEBUG] Closed socket 7 (AF_INET 127.0.0.1:3350)
[20170804-03:08:48] [DEBUG] Closed socket 8 (AF_INET 127.0.0.1:3350)
[20170804-03:08:48] [INFO ] Xorg :10 -auth .Xauthority -config xrdp/xorg.conf -noreset -nolisten tcp -logfile .xorgxrdp.%s.log
X.Org X Server 1.18.4
Release Date: 2016-07-19
X Protocol Version 11, Revision 0
Build Operating System: Linux 4.4.0-53-generic x86_64 Ubuntu
Current Operating System: Linux netdev1-westus2.phx.gbl 4.4.0-87-generic #110-Ubuntu SMP Tue Jul 18 12:55:35 UTC 2017 x86_64
Kernel command line: BOOT_IMAGE=/boot/vmlinuz-4.4.0-87-generic root=UUID=567ab888-a3b5-43d4-a92a-f594e8653924 ro console=tty1 console=ttyS0 earlyprintk=ttyS0 rootdelay=300
Build Date: 15 December 2016 11:49:05AM
xorg-server 2:1.18.4-1ubuntu9 (For technical support please see http://www.ubuntu.com/support)
Current version of pixman: 0.33.6
Before reporting problems, check http://wiki.x.org
to make sure that you have the latest version.
Markers: (--) probed, (**) from config file, (==) default setting,
(++) from command line, (!!) notice, (II) informational,
(WW) warning, (EE) error, (NI) not implemented, (??) unknown.
(++) Log file: ".xorgxrdp.10.log", Time: Fri Aug 4 03:08:48 2017
(==) Using system config directory "/usr/share/X11/xorg.conf.d"
(EE)
Fatal server error:
(EE) parse_vt_settings: Cannot open /dev/tty0 (Permission denied)
(EE)
(EE)
Please consult the The X.Org Foundation support
at http://wiki.x.org
for help.
(EE) Please also check the log file at ".xorgxrdp.10.log" for additional information.
(EE)
(EE) Server terminated with error (1). Closing log file.
[20170804-03:08:58] [ERROR] X server for display 10 startup timeout
[20170804-03:08:58] [ERROR] X server for display 10 startup timeout
[20170804-03:08:58] [CORE ] waiting for window manager (pid 7069) to exit
chansrv::main: using log file [/home/johnar/.local/share/xrdp/xrdp-chansrv.10.log]
[20170804-03:08:58] [CORE ] main: app started pid 7073(0x00001ba1)
[20170804-03:08:58] [ERROR] another Xserver might already be active on display 10 - see log
[20170804-03:08:58] [INFO ] main: DISPLAY env var set to :10.0
[20170804-03:08:58] [INFO ] main: using DISPLAY 10
[20170804-03:08:58] [DEBUG] aborting connection...
[20170804-03:08:58] [INFO ] channel_thread_loop: thread start
[20170804-03:08:58] [CORE ] window manager (pid 7069) did exit, cleaning up session
[20170804-03:08:58] [INFO ] calling auth_stop_session and auth_end from pid 7068
[20170804-03:08:58] [INFO ] term_signal_handler: got signal 15
[20170804-03:08:58] [INFO ] ++ terminated session: username johnar, display :10.0, session_pid 7068, ip 10.64.3.54:50252 - socket: 12
[20170804-03:08:58] [INFO ] channel_thread_loop: g_term_event set
xrdp-chansrv [2872552441]: scard_deinit:
chansrv:smartcard_pcsc [2872552441]: scard_pcsc_deinit:
[20170804-03:08:58] [INFO ] channel_thread_loop: thread stop
[20170804-03:08:58] [INFO ] main: app exiting pid 7073(0x00001ba1)
^C[20170804-03:09:18] [INFO ] shutting down sesman 1
[20170804-03:09:18] [DEBUG] Closed socket 7 (AF_INET 127.0.0.1:3350)
[20170804-03:09:18] [CORE ] shutting down log subsystem...
johnar@netdev1-westus2:~$
@metalefty
parse_vt_settings: Cannot open /dev/tty0 (Permission denied)
this fairly reeks of more suid issues. I (re)installed xserver-xorg-legacy and reconfigured to allow anybody, same results.
johnarnold
on 4 Aug 2017
I've setup Ubuntu 16.04 environment maybe as same as yours overall.
If Xorg with xrdp module (called xorgxrdp) is properly stating, the output will be like this.
X.Org X Server 1.18.4
Release Date: 2016-07-19
X Protocol Version 11, Revision 0
Build Operating System: Linux 4.4.0-83-generic x86_64 Ubuntu
Current Operating System: Linux ip-10-100-102-20 4.4.0-66-generic #87-Ubuntu SMP Fri Mar 3 15:29:05 UTC 2017 x86_64
Kernel command line: BOOT_IMAGE=/boot/vmlinuz-4.4.0-66-generic root=UUID=19a80b3b-0a7d-4b08-b7a0-d5c549875d0d ro console=t
ty1 console=ttyS0
Build Date: 17 July 2017 05:05:12PM
xorg-server 2:1.18.4-0ubuntu0.3 (For technical support please see http://www.ubuntu.com/support)
Current version of pixman: 0.33.6
Before reporting problems, check http://wiki.x.org
to make sure that you have the latest version.
Markers: (--) probed, (**) from config file, (==) default setting,
(++) from command line, (!!) notice, (II) informational,
(WW) warning, (EE) error, (NI) not implemented, (??) unknown.
(==) Log file: "/home/ubuntu/.local/share/xorg/Xorg.10.log", Time: Fri Aug 4 04:30:36 2017
(++) Using config file: "/etc/X11/xrdp/xorg.conf"
(==) Using system config directory "/usr/share/X11/xorg.conf.d"
xorgxrdpSetup:
xrdpdevSetup:
(snip)
The difference between my Xorg log and yours is this line. Can you confirm xrdp's xorg.conf is properly located? Typically it is located /etc/X11/xrdp/xorg.conf.
(++) Using config file: "/etc/X11/xrdp/xorg.conf"
And please also try Xorg :10 # not specifying config file? It will fail with the following error but it is normal.
(EE) parse_vt_settings: Cannot open /dev/tty0 (Permission denied)
I tried Xorg :10 -config /etc/X11/not-existing-xorg.conf and it shows the permission error above. At least for me, the Xorg's permission error occurs when not specifying config file or config file doesn't exist. I suspect your /etc/X11/xrdp/xorg.conf doesn't exist.
metalefty
on 4 Aug 2017
Looks like it's missing:
johnar@netdev1-westus2:~$ sudo ls /etc/X11/xrdp
ls: cannot access '/etc/X11/xrdp': No such file or directory
johnar@netdev1-westus2:~$ sudo ls /etc/X11/
app-defaults fonts rgb.txt xinit xkb Xreset Xreset.d Xresources Xsession Xsession.d Xsession.options Xwrapper.config
That seems to be the root cause of your issue. xorgxrdp is not properly installed.
Typically, xorgxrdp installs these files. *.la files may not be installed depending on environment.
/usr/lib/xorg/modules/libxorgxrdp.a
/usr/lib/xorg/modules/drivers/xrdpdev_drv.la
/usr/lib/xorg/modules/drivers/xrdpdev_drv.a
/usr/lib/xorg/modules/drivers/xrdpdev_drv.so
/usr/lib/xorg/modules/libxorgxrdp.so
/usr/lib/xorg/modules/input/xrdpmouse_drv.la
/usr/lib/xorg/modules/input/xrdpkeyb_drv.so
/usr/lib/xorg/modules/input/xrdpkeyb_drv.la
/usr/lib/xorg/modules/input/xrdpmouse_drv.a
/usr/lib/xorg/modules/input/xrdpmouse_drv.so
/usr/lib/xorg/modules/input/xrdpkeyb_drv.a
/usr/lib/xorg/modules/libxorgxrdp.la
/etc/X11/xrdp/xorg.conf
This is kind of interesting... I tried manual (not scripted) rebuild of xorgxrdp:
johnar@netdev1-westus2:/var/tmp/git/neutrinolabs/xorgxrdp$ sudo make install
Making install in module
make[1]: Entering directory '/var/tmp/git/neutrinolabs/xorgxrdp/module'
Making install in amd64
make[2]: Entering directory '/var/tmp/git/neutrinolabs/xorgxrdp/module/amd64'
make[3]: Entering directory '/var/tmp/git/neutrinolabs/xorgxrdp/module/amd64'
make[3]: Nothing to be done for 'install-exec-am'.
make[3]: Nothing to be done for 'install-data-am'.
make[3]: Leaving directory '/var/tmp/git/neutrinolabs/xorgxrdp/module/amd64'
make[2]: Leaving directory '/var/tmp/git/neutrinolabs/xorgxrdp/module/amd64'
make[2]: Entering directory '/var/tmp/git/neutrinolabs/xorgxrdp/module'
CC rdpDraw.lo
In file included from /usr/include/xorg/dixfontstr.h:28:0,
from rdpDraw.c:44:
/usr/include/xorg/dixfont.h:32:32: fatal error: X11/fonts/fontutil.h: No such file or directory
Somebody else encountered similar:
https://bugs.freedesktop.org/show_bug.cgi?id=101968
johnarnold
on 4 Aug 2017
I happen to have libxfont-dev installed too...
johnar@netdev1-westus2:/var/tmp/git/neutrinolabs/xorgxrdp$ apt-cache policy libxfont-dev
libxfont-dev:
Installed: 1:2.0.1-3~ubuntu16.04.1
It is neutrinolabs/xorgxrdp#100.
Install either pair of packages.
- xserver-xorg-dev & libxfont1-dev
- xserver-xorg-dev-hwe-16.04 & libxfont-dev.
metalefty
on 4 Aug 2017
metalefty
on 4 Aug 2017
Unfortunately this is not the cause of my issue- the arch package correctly installs that xrdp folder.
~/.xorgxrdp.10.log http://sprunge.us/WDaE
/var/log/xrdp.log http://sprunge.us/LdXj
/var/log/xrdp-sesman.log http://sprunge.us/VILg
AeliusSaionji
on 4 Aug 2017
Interesting. I wasn't able to install the first or second pair, due to repo issues (503)...
johnar@netdev1-westus2:/var/tmp/git/neutrinolabs/xorgxrdp$ sudo apt-get install libxfont1-dev
Reading package lists... Done
Building dependency tree
Reading state information... Done
The following NEW packages will be installed:
libxfont1-dev
0 upgraded, 1 newly installed, 0 to remove and 14 not upgraded.
Need to get 126 kB of archives.
After this operation, 478 kB of additional disk space will be used.
Err:1 http://azure.archive.ubuntu.com/ubuntu xenial-updates/main amd64 libxfont1-dev amd64 1:1.5.1-1ubuntu0.16.04.1
503 Service Unavailable
E: Failed to fetch http://azure.archive.ubuntu.com/ubuntu/pool/main/libx/libxfont/libxfont1-dev_1.5.1-1ubuntu0.16.04.1_amd64.deb 503 Service Unavailable
E: Unable to fetch some archives, maybe run apt-get update or try with --fix-missing?
johnar@netdev1-westus2:/var/tmp/git/neutrinolabs/xorgxrdp$ sudo apt-get install xserver-xorg-dev-hwe-16.04 libxfont-dev
Reading package lists... Done
Building dependency tree
Reading state information... Done
The following NEW packages will be installed:
libxfont-dev xserver-xorg-dev-hwe-16.04
0 upgraded, 2 newly installed, 0 to remove and 14 not upgraded.
Need to get 200 kB/324 kB of archives.
After this operation, 1,944 kB of additional disk space will be used.
Err:1 http://azure.archive.ubuntu.com/ubuntu xenial-updates/main amd64 xserver-xorg-dev-hwe-16.04 amd64 2:1.19.3-1ubuntu1~16.04.2
503 Service Unavailable
E: Failed to fetch http://azure.archive.ubuntu.com/ubuntu/pool/main/x/xorg-server-hwe-16.04/xserver-xorg-dev-hwe-16.04_1.19.3-1ubuntu1~16.04.2_amd64.deb 503 Service Unavailable
but can install with --fix-missing...
libxfont1-dev also seems to be messed up...
Unpacking libxfont1-dev (1:1.5.1-1ubuntu0.16.04.1) ...
dpkg: error processing archive /var/cache/apt/archives/libxfont1-dev_1%3a1.5.1-1ubuntu0.16.04.1_amd64.deb (--unpack):
trying to overwrite '/usr/share/doc/libxfont-dev/fontlib.html', which is also in package libxfont-dev 1:2.0.1-3~ubuntu16.04.1
(I had already removed libxfont-dev...
This seems to work ok:
sudo apt-get remove -y xserver-xorg-dev libxfont-dev
sudo apt-get install -y xserver-xorg-dev-hwe-16.04 libxfont-dev --fix-missing
I can confirm that this resolved my issues under Ubuntu 16.04. I was able to launch mate-session using my normal startwm.sh, no issues. Hope it helps someone else too. Maybe an update of the build dependencies in the readme's is in order.
Thank you @metalefty for the support!
johnarnold
on 4 Aug 2017
Well, guess i'm not getting off "that easy." I tried to repeat my success on another server, and no joy. This time i'm not getting the compile error on xfonts, and the config file loads for xorgrdp, but I still get the permissions error:
xorg-server 2:1.18.4-1ubuntu9 (For technical support please see http://www.ubuntu.com/support)
Current version of pixman: 0.33.6
Before reporting problems, check http://wiki.x.org
to make sure that you have the latest version.
Markers: (--) probed, (**) from config file, (==) default setting,
(++) from command line, (!!) notice, (II) informational,
(WW) warning, (EE) error, (NI) not implemented, (??) unknown.
(++) Log file: ".xorgxrdp.10.log", Time: Fri Aug 4 00:24:16 2017
(++) Using config file: "/etc/X11/xrdp/xorg.conf"
(==) Using system config directory "/usr/share/X11/xorg.conf.d"
(EE) module ABI major version (23) doesn't match the server's version (20)
(EE) module ABI major version (24) doesn't match the server's version (22)
(EE) module ABI major version (24) doesn't match the server's version (22)
(EE)
Fatal server error:
(EE) parse_vt_settings: Cannot open /dev/tty0 (Permission denied)
(EE)
(EE)
Please consult the The X.Org Foundation support
at http://wiki.x.org
for help.
(EE) Please also check the log file at ".xorgxrdp.10.log" for additional information.
(EE)
(EE) Server terminated with error (1). Closing log file.
[20170804-00:24:25] [ERROR] X server for display 10 startup timeout
[20170804-00:24:25] [CORE ] waiting for window manager (pid 8625) to exit
chansrv::main: using log file [/home/johnar/.local/share/xrdp/xrdp-chansrv.0.log]
[20170804-00:24:25] [CORE ] main: app started pid 8634(0x000021ba)
[20170804-00:24:25] [INFO ] main: DISPLAY env var set to (null)
[20170804-00:24:25] [ERROR] main: error, display is zero
[20170804-00:24:26] [ERROR] X server for display 10 startup timeout
[20170804-00:24:26] [ERROR] another Xserver might already be active on display 10 - see log
[20170804-00:24:26] [DEBUG] aborting connection...
[20170804-00:24:26] [CORE ] window manager (pid 8625) did exit, cleaning up session
[20170804-00:24:26] [INFO ] calling auth_stop_session and auth_end from pid 8624
[20170804-00:24:26] [INFO ] ++ terminated session: username johnar, display :10.0, session_pid 8624, ip 10.64.3.54:25264 - socket: 12
confirmed the right dev packages:
johnar@nettools1-co1:/var/tmp$ dpkg -l | grep -e libxfont -e xserver-xorg-dev
ii libxfont-dev 1:2.0.1-3~ubuntu16.04.1 amd64 X11 font rasterisation library (development headers)
ii libxfont1:amd64 1:1.5.1-1ubuntu0.16.04.1 amd64 X11 font rasterisation library
ii libxfont2:amd64 1:2.0.1-3~ubuntu16.04.1 amd64 X11 font rasterisation library
ii xserver-xorg-dev-hwe-16.04 2:1.19.3-1ubuntu1~16.04.2 amd64 Xorg X server - development files
ABI problem looks bad...
[3806327.563] (II) LoadModule: "xrdpmouse"
[3806327.563] (II) Loading /usr/lib/xorg/modules/input/xrdpmouse_drv.so
[3806327.564] (II) Module XRDPMOUSE: vendor="X.Org Foundation"
[3806327.564] compiled for 1.19.3, module version = 1.0.0
[3806327.564] Module class: X.Org XInput Driver
[3806327.564] ABI class: X.Org XInput driver, version 24.1
[3806327.564] (EE) module ABI major version (24) doesn't match the server's version (22)
[3806327.564] (II) UnloadModule: "xrdpmouse"
[3806327.564] (II) Unloading xrdpmouse
[3806327.564] (EE) Failed to load module "xrdpmouse" (module requirement mismatch, 0)
[3806327.564] (II) LoadModule: "xrdpkeyb"
[3806327.564] (II) Loading /usr/lib/xorg/modules/input/xrdpkeyb_drv.so
[3806327.564] (II) Module XRDPKEYB: vendor="X.Org Foundation"
[3806327.564] compiled for 1.19.3, module version = 1.0.0
[3806327.564] Module class: X.Org XInput Driver
[3806327.564] ABI class: X.Org XInput driver, version 24.1
[3806327.564] (EE) module ABI major version (24) doesn't match the server's version (22)
[3806327.564] (II) UnloadModule: "xrdpkeyb"
[3806327.564] (II) Unloading xrdpkeyb
[3806327.564] (EE) Failed to load module "xrdpkeyb" (module requirement mismatch, 0)
[3806327.564] (II) modesetting: Driver for Modesetting Kernel Drivers: kms
[3806327.564] (EE)
Fatal server error:
[3806327.565] (EE) parse_vt_settings: Cannot open /dev/tty0 (Permission denied)
[3806327.565] (EE)
[3806327.565] (EE)
Please consult the The X.Org Foundation support
at http://wiki.x.org
for help.
[3806327.565] (EE) Please also check the log file at ".xorgxrdp.10.log" for additional information.
[3806327.565] (EE)
Yes, xrdp module is not loaded due to ABI mismatch. It leads Xorg to the same result as if nonexistent config file specified.
metalefty
on 4 Aug 2017
Can you try xserver-xorg-dev & libxfont1-dev pair? It worked for me.
I tried xserver-xorg-dev-hwe-16.04 & libxfont-dev pair, I got the same result as yours.
metalefty
on 4 Aug 2017
Any thoughts on what I could try @metalefty ?
AeliusSaionji
on 4 Aug 2017
@Link-Satonaka you may want to open a separate issue, just to minimize confusion.
johnarnold
on 4 Aug 2017
@metalefty
For some reason I just can't install libxfont1-dev... even after apt-get purge libxfont-dev
Unpacking libxfont1-dev (1:1.5.1-1ubuntu0.16.04.1) ...
dpkg: error processing archive /var/cache/apt/archives/libxfont1-dev_1%3a1.5.1-1ubuntu0.16.04.1_amd64.deb (--unpack):
trying to overwrite '/usr/share/doc/libxfont-dev/fontlib.html', which is also in package libxfont-dev 1:2.0.1-3~ubuntu16.04.1
I tried downloading the latest libxfont1-dev from another mirror just to confirm it's not an issue with the mirror I'm using, but I get the same result. Tried clearing apt cache, tried forcing install, no go. I'm curious how you were able to get libxfont1-dev to install?
johnarnold
on 4 Aug 2017
Ugh. ok. I think the problem there was that xserver-xorg-dev depends on (forces reinstall of) libxfont-dev, causing the conflict with libxfont1-dev. Can't install xserver-xorg-dev before libxfont1-dev or it blows up. Can't install at the same time or it blows up.
Have to do:
sudo apt-get remove -y xserver-xorg-dev-hwe-16.04 libxfont-dev
sudo apt-get install -y libxfont1-dev
sudo apt-get install -y xserver-xorg-dev
... you still get an error on xserver-xorg-dev which tries to re-install libxfont-dev, but at least it completes.
The following packages have unmet dependencies:
xserver-xorg-dev : Depends: libxfont-dev but it is not going to be installed
Unfortunately, that still leaves me with ABI conflicts in xrdp-sesman. I'm stumped.
johnarnold
on 4 Aug 2017
@metalefty The package list looks right, does this match yours?
johnar@nettools1-co1:/var/tmp/git/neutrinolabs/xrdp$ sudo dpkg -l | grep libxfont
ii libxfont1:amd64 1:1.5.1-1ubuntu0.16.04.1 amd64 X11 font rasterisation library
ii libxfont1-dev 1:1.5.1-1ubuntu0.16.04.1 amd64 X11 font rasterisation library (development headers)
ii libxfont2:amd64 1:2.0.1-3~ubuntu16.04.1 amd64 X11 font rasterisation library
johnar@nettools1-co1:/var/tmp/git/neutrinolabs/xrdp$ sudo dpkg -l | grep xserver-xorg-dev
iU xserver-xorg-dev 2:1.18.4-0ubuntu0.3 amd64 Xorg X server - development files
johnar@nettools1-co1:/var/tmp/git/neutrinolabs/xrdp$
xorg-server 2:1.18.4-1ubuntu9 (For technical support please see http://www.ubuntu.com/support)
Current version of pixman: 0.33.6
Before reporting problems, check http://wiki.x.org
to make sure that you have the latest version.
Markers: (--) probed, (**) from config file, (==) default setting,
(++) from command line, (!!) notice, (II) informational,
(WW) warning, (EE) error, (NI) not implemented, (??) unknown.
(++) Log file: ".xorgxrdp.10.log", Time: Fri Aug 4 09:06:24 2017
(++) Using config file: "/etc/X11/xrdp/xorg.conf"
(==) Using system config directory "/usr/share/X11/xorg.conf.d"
(EE) module ABI major version (23) doesn't match the server's version (20)
(EE) module ABI major version (24) doesn't match the server's version (22)
(EE) module ABI major version (24) doesn't match the server's version (22)
(EE)
Fatal server error:
(EE) parse_vt_settings: Cannot open /dev/tty0 (Permission denied)
(EE)
(EE)
I'll check it & answer on Monday.
metalefty
on 5 Aug 2017
Just for record, the issue is now filed Ubuntu launchpad and in progress.
https://bugs.launchpad.net/ubuntu/+source/libxfont/+bug/1707691
metalefty
on 8 Aug 2017
Same issue here, Ubuntu 16.04, just installed the latest LTS updates and got the black screen.
I built xrdp and xorgxrdp from the latest git pull (d9b929c1 for xrdp and bdda5277 for xorgxrdp)
With help of the launchpad ticket I was able to untangle the packaging mess arounf libxfont (by pulling from the xenial-proposed repository) and to build xorgxrdp successfully.
I have tried the Xwrapper thing, doesn't change anything.
Here are the versions of all the stuff:
ii libxfont1:amd64 1:1.5.1-1ubuntu0.16.04.2 amd64 X11 font rasterisation library
ii libxfont1-dev 1:1.5.1-1ubuntu0.16.04.2 amd64 X11 font rasterisation library (development headers)
ii libxfont2:amd64 1:2.0.1-3~ubuntu16.04.1 amd64 X11 font rasterisation library
ii xserver-xorg-dev 2:1.18.4-0ubuntu0.4 amd64 Xorg X server - development files
(Note where the libxfont1-dev package comes from, as well as the corresponding apt-pinning for xenial-proposed:)
$ apt-cache policy libxfont1-dev
libxfont1-dev:
Installed: 1:1.5.1-1ubuntu0.16.04.2
Candidate: 1:1.5.1-1ubuntu0.16.04.2
Version table:
*** 1:1.5.1-1ubuntu0.16.04.2 400
400 http://sg.archive.ubuntu.com/ubuntu xenial-proposed/main amd64 Packages
100 /var/lib/dpkg/status
1:1.5.1-1ubuntu0.16.04.1 500
500 http://sg.archive.ubuntu.com/ubuntu xenial-updates/main amd64 Packages
Logs from syslog:
Aug 15 13:02:41 the-server1 systemd[1]: Stopping xrdp daemon...
Aug 15 13:02:41 the-server1 xrdp[11257]: (11257)(140007743723264)[DEBUG] Closed socket 11 (AF_INET 0.0.0.0:3389)
Aug 15 13:02:41 the-server1 xrdp[11257]: (11257)(140007743723264)[CORE ] shutting down log subsystem...
Aug 15 13:02:41 the-server1 systemd[1]: Stopped xrdp daemon.
Aug 15 13:02:41 the-server1 systemd[1]: Stopping xrdp session manager...
Aug 15 13:02:41 the-server1 xrdp-sesman[11254]: (11254)(139709975459584)[INFO ] shutting down sesman 1
Aug 15 13:02:41 the-server1 xrdp-sesman[11254]: (11254)(139709975459584)[INFO ] shutting down sesman 1
Aug 15 13:02:41 the-server1 xrdp-sesman[11254]: (11254)(139709975459584)[DEBUG] Closed socket 7 (AF_INET 127.0.0.1:3350)
Aug 15 13:02:41 the-server1 systemd[1]: Stopped xrdp session manager.
Aug 15 13:02:41 the-server1 systemd[1]: Starting xrdp session manager...
Aug 15 13:02:41 the-server1 xrdp-sesman[12095]: (12095)(140152460060416)[DEBUG] libscp initialized
Aug 15 13:02:41 the-server1 xrdp-sesman[12095]: (12095)(140152460060416)[DEBUG] Testing if xrdp-sesman can listen on 127.0.0.1 port 3350.
Aug 15 13:02:41 the-server1 xrdp-sesman[12096]: (12096)(140152460060416)[INFO ] starting xrdp-sesman with pid 12096
Aug 15 13:02:41 the-server1 xrdp-sesman[12095]: (12095)(140152460060416)[DEBUG] Closed socket 5 (AF_INET 127.0.0.1:3350)
Aug 15 13:02:41 the-server1 xrdp-sesman[12096]: (12096)(140152460060416)[INFO ] listening to port 3350 on 127.0.0.1
Aug 15 13:02:41 the-server1 systemd[1]: Started xrdp session manager.
Aug 15 13:02:41 the-server1 systemd[1]: Starting xrdp daemon...
Aug 15 13:02:41 the-server1 xrdp[12098]: (12098)(140270506342144)[DEBUG] Testing if xrdp can listen on 0.0.0.0 port 3389.
Aug 15 13:02:41 the-server1 xrdp[12098]: (12098)(140270506342144)[DEBUG] Closed socket 7 (AF_INET 0.0.0.0:3389)
Aug 15 13:02:41 the-server1 systemd[1]: xrdp.service: PID file /var/run/xrdp.pid not readable (yet?) after start: No such file or directory
Aug 15 13:02:42 the-server1 systemd[1]: Started xrdp daemon.
Aug 15 13:02:43 the-server1 xrdp[12103]: (12103)(140270506342144)[INFO ] starting xrdp with pid 12103
Aug 15 13:02:43 the-server1 xrdp[12103]: (12103)(140270506342144)[INFO ] listening to port 3389 on 0.0.0.0
Aug 15 13:03:52 the-server1 xrdp[12103]: (12103)(140270506342144)[INFO ] Socket 12: AF_INET connection received from 10.25.191.128 port 50091
Aug 15 13:03:52 the-server1 xrdp[12103]: (12103)(140270506342144)[DEBUG] Closed socket 12 (AF_INET 10.25.191.164:3389)
Aug 15 13:03:52 the-server1 xrdp[12427]: (12427)(140270506342144)[DEBUG] Closed socket 11 (AF_INET 0.0.0.0:3389)
Aug 15 13:03:52 the-server1 xrdp[12427]: (12427)(140270506342144)[INFO ] Using default X.509 certificate: /etc/xrdp/cert.pem
Aug 15 13:03:52 the-server1 xrdp[12427]: (12427)(140270506342144)[INFO ] Using default X.509 key file: /etc/xrdp/key.pem
Aug 15 13:03:52 the-server1 xrdp[12427]: (12427)(140270506342144)[DEBUG] TLSv1.2 enabled
Aug 15 13:03:52 the-server1 xrdp[12427]: (12427)(140270506342144)[DEBUG] TLSv1.1 enabled
Aug 15 13:03:52 the-server1 xrdp[12427]: (12427)(140270506342144)[DEBUG] TLSv1 enabled
Aug 15 13:03:52 the-server1 xrdp[12427]: (12427)(140270506342144)[DEBUG] Security layer: requested 11, selected 1
Aug 15 13:03:52 the-server1 xrdp[12427]: (12427)(140270506342144)[DEBUG] Closed socket 12 (AF_INET 10.25.191.164:3389)
Aug 15 13:03:52 the-server1 xrdp[12427]: (12427)(140270506342144)[ERROR] Listening socket is in wrong state, terminating listener
Aug 15 13:03:52 the-server1 xrdp[12427]: (12427)(140270506342144)[CORE ] shutting down log subsystem...
Aug 15 13:03:52 the-server1 xrdp[12103]: (12103)(140270506342144)[INFO ] Socket 12: AF_INET connection received from 10.25.191.128 port 50092
Aug 15 13:03:52 the-server1 xrdp[12103]: (12103)(140270506342144)[DEBUG] Closed socket 12 (AF_INET 10.25.191.164:3389)
Aug 15 13:03:52 the-server1 xrdp[12428]: (12428)(140270506342144)[DEBUG] Closed socket 11 (AF_INET 0.0.0.0:3389)
Aug 15 13:03:52 the-server1 xrdp[12428]: (12428)(140270506342144)[INFO ] Using default X.509 certificate: /etc/xrdp/cert.pem
Aug 15 13:03:52 the-server1 xrdp[12428]: (12428)(140270506342144)[INFO ] Using default X.509 key file: /etc/xrdp/key.pem
Aug 15 13:03:52 the-server1 xrdp[12428]: (12428)(140270506342144)[DEBUG] TLSv1.2 enabled
Aug 15 13:03:52 the-server1 xrdp[12428]: (12428)(140270506342144)[DEBUG] TLSv1.1 enabled
Aug 15 13:03:52 the-server1 xrdp[12428]: (12428)(140270506342144)[DEBUG] TLSv1 enabled
Aug 15 13:03:52 the-server1 xrdp[12428]: (12428)(140270506342144)[DEBUG] Security layer: requested 11, selected 1
Aug 15 13:03:52 the-server1 xrdp[12428]: (12428)(140270506342144)[INFO ] connected client computer name: the-MARC
Aug 15 13:03:52 the-server1 xrdp[12428]: (12428)(140270506342144)[INFO ] TLS connection established from 10.25.191.128 port 50092: TLSv1.2 with cipher AES256-GCM-SHA384
Aug 15 13:03:52 the-server1 xrdp[12428]: (12428)(140270506342144)[DEBUG] xrdp_0000308c_wm_login_mode_event_00000001
Aug 15 13:03:52 the-server1 xrdp[12428]: (12428)(140270506342144)[INFO ] Cannot find keymap file /etc/xrdp/km-00020409.ini
Aug 15 13:03:52 the-server1 xrdp[12428]: (12428)(140270506342144)[INFO ] Loading keymap file /etc/xrdp/km-00000409.ini
Aug 15 13:03:52 the-server1 xrdp[12428]: (12428)(140270506342144)[WARN ] local keymap file for 0x00020409 found and doesn't match built in keymap, using local keymap file
Aug 15 13:03:52 the-server1 xrdp[12428]: (12428)(140270506342144)[DEBUG] xrdp_wm_log_msg: connecting to sesman ip 127.0.0.1 port 3350
Aug 15 13:03:52 the-server1 xrdp-sesman[12096]: (12096)(140152460060416)[INFO ] A connection received from 127.0.0.1 port 45402
Aug 15 13:03:52 the-server1 xrdp[12428]: (12428)(140270506342144)[INFO ] xrdp_wm_log_msg: sesman connect ok
Aug 15 13:03:52 the-server1 xrdp[12428]: (12428)(140270506342144)[DEBUG] xrdp_wm_log_msg: sending login info to session manager, please wait...
Aug 15 13:03:52 the-server1 xrdp[12428]: (12428)(140270506342144)[DEBUG] return value from xrdp_mm_connect 0
Aug 15 13:03:52 the-server1 xrdp-sesman[12096]: (12096)(140152460060416)[INFO ] ++ created session (access granted): username johndoe, ip 10.25.191.128:50092 - socket: 12
Aug 15 13:03:52 the-server1 xrdp-sesman[12096]: (12096)(140152460060416)[INFO ] starting Xorg session...
Aug 15 13:03:52 the-server1 xrdp-sesman[12096]: (12096)(140152460060416)[DEBUG] Closed socket 9 (AF_INET 0.0.0.0:5910)
Aug 15 13:03:52 the-server1 xrdp-sesman[12096]: (12096)(140152460060416)[DEBUG] Closed socket 9 (AF_INET 0.0.0.0:6010)
Aug 15 13:03:52 the-server1 xrdp-sesman[12096]: (12096)(140152460060416)[DEBUG] Closed socket 9 (AF_INET 0.0.0.0:6210)
Aug 15 13:03:52 the-server1 xrdp-sesman[12096]: (12096)(140152460060416)[DEBUG] Closed socket 8 (AF_INET 127.0.0.1:3350)
Aug 15 13:03:52 the-server1 xrdp[12428]: (12428)(140270506342144)[INFO ] xrdp_wm_log_msg: login successful for display 10
Aug 15 13:03:52 the-server1 xrdp-sesman[12429]: (12429)(140152460060416)[INFO ] calling auth_start_session from pid 12429
Aug 15 13:03:53 the-server1 xrdp[12428]: (12428)(140270506342144)[DEBUG] xrdp_wm_log_msg: started connecting
Aug 15 13:03:53 the-server1 xrdp-sesman[12429]: pam_unix(xrdp-sesman:session): session opened for user johndoe by (uid=0)
Aug 15 13:03:53 the-server1 systemd-logind[1294]: New session c7 of user johndoe.
Aug 15 13:03:53 the-server1 systemd[1]: Started Session c7 of user johndoe.
Aug 15 13:03:53 the-server1 xrdp-sesman[12429]: (12429)(140152460060416)[DEBUG] Closed socket 7 (AF_INET 127.0.0.1:3350)
Aug 15 13:03:53 the-server1 xrdp-sesman[12429]: (12429)(140152460060416)[DEBUG] Closed socket 8 (AF_INET 127.0.0.1:3350)
Aug 15 13:03:53 the-server1 xrdp-sesman[12431]: (12431)(140152460060416)[INFO ] Xorg :10 -auth .Xauthority -config xrdp/xorg.conf -noreset -nolisten tcp -logfile .xorgxrdp.%s.log
Aug 15 13:03:56 the-server1 xrdp[12428]: (12428)(140270506342144)[DEBUG] Closed socket 19 (AF_UNIX)
Aug 15 13:04:00 the-server1 xrdp[12428]: (12428)(140270506342144)[DEBUG] Closed socket 19 (AF_UNIX)
Aug 15 13:04:02 the-server1 xrdp-sesman[12429]: (12429)(140152460060416)[ERROR] X server for display 10 startup timeout
Aug 15 13:04:02 the-server1 xrdp-sesman[12429]: (12429)(140152460060416)[CORE ] waiting for window manager (pid 12430) to exit
Aug 15 13:04:03 the-server1 xrdp-sesman[12430]: (12430)(140152460060416)[ERROR] X server for display 10 startup timeout
Aug 15 13:04:03 the-server1 xrdp-sesman[12430]: (12430)(140152460060416)[ERROR] another Xserver might already be active on display 10 - see log
Aug 15 13:04:03 the-server1 xrdp-sesman[12430]: (12430)(140152460060416)[DEBUG] aborting connection...
Aug 15 13:04:03 the-server1 xrdp-sesman[12429]: (12429)(140152460060416)[CORE ] window manager (pid 12430) did exit, cleaning up session
Aug 15 13:04:03 the-server1 xrdp-sesman[12429]: (12429)(140152460060416)[INFO ] calling auth_stop_session and auth_end from pid 12429
Aug 15 13:04:03 the-server1 xrdp-sesman[12429]: pam_unix(xrdp-sesman:session): session closed for user johndoe
Aug 15 13:04:03 the-server1 xrdp-sesman[12096]: (12096)(140152460060416)[INFO ] ++ terminated session: username johndoe, display :10.0, session_pid 12429, ip 10.25.191.128:50092 - socket: 12
Aug 15 13:04:03 the-server1 systemd-logind[1294]: Removed session c7.
Aug 15 13:04:03 the-server1 xrdp[12428]: (12428)(140270506342144)[DEBUG] Closed socket 19 (AF_UNIX)
Aug 15 13:04:07 the-server1 xrdp[12428]: (12428)(140270506342144)[DEBUG] Closed socket 19 (AF_UNIX)
The issue seems to start when launching Xorg :10 -auth .Xauthority -config xrdp/xorg.conf -noreset -nolisten tcp -logfile .xorgxrdp.%s.log
Here is the content of .xorgxrdp.10.log:
[ 3619.254]
X.Org X Server 1.19.3
Release Date: 2017-03-15
[ 3619.254] X Protocol Version 11, Revision 0
[ 3619.254] Build Operating System: Linux 4.4.0-87-generic x86_64 Ubuntu
[ 3619.254] Current Operating System: Linux the-server1 4.10.0-32-generic #36~16.04.1-Ubuntu SMP Wed Aug 9 09:19:02 UTC 2017 x86_64
[ 3619.254] Kernel command line: BOOT_IMAGE=/boot/vmlinuz-4.10.0-32-generic root=UUID=77bd31b6-dd31-484d-b443-5c6b93b7dc4a ro quiet splash vt.handoff=7
[ 3619.254] Build Date: 25 July 2017 01:30:08PM
[ 3619.254] xorg-server 2:1.19.3-1ubuntu1~16.04.2 (For technical support please see http://www.ubuntu.com/support)
[ 3619.254] Current version of pixman: 0.33.6
[ 3619.254] Before reporting problems, check http://wiki.x.org
to make sure that you have the latest version.
[ 3619.254] Markers: (--) probed, (**) from config file, (==) default setting,
(++) from command line, (!!) notice, (II) informational,
(WW) warning, (EE) error, (NI) not implemented, (??) unknown.
[ 3619.254] (++) Log file: ".xorgxrdp.10.log", Time: Tue Aug 15 13:10:34 2017
[ 3619.254] (++) Using config file: "/etc/X11/xrdp/xorg.conf"
[ 3619.254] (==) Using system config directory "/usr/share/X11/xorg.conf.d"
[ 3619.255] (==) ServerLayout "X11 Server"
[ 3619.255] (**) |-->Screen "Screen (xrdpdev)" (0)
[ 3619.255] (**) | |-->Monitor "Monitor"
[ 3619.255] (**) | |-->Device "Video Card (xrdpdev)"
[ 3619.255] (**) |-->Input Device "xrdpMouse"
[ 3619.255] (**) |-->Input Device "xrdpKeyboard"
[ 3619.255] (**) Option "DontVTSwitch" "on"
[ 3619.255] (**) Option "AutoAddDevices" "off"
[ 3619.255] (**) Not automatically adding devices
[ 3619.255] (==) Automatically enabling devices
[ 3619.255] (==) Automatically adding GPU devices
[ 3619.255] (==) Automatically binding GPU devices
[ 3619.255] (==) Max clients allowed: 256, resource mask: 0x1fffff
[ 3619.255] (WW) The directory "/usr/share/fonts/X11/cyrillic" does not exist.
[ 3619.255] Entry deleted from font path.
[ 3619.255] (WW) The directory "/usr/share/fonts/X11/100dpi/" does not exist.
[ 3619.255] Entry deleted from font path.
[ 3619.255] (WW) The directory "/usr/share/fonts/X11/75dpi/" does not exist.
[ 3619.255] Entry deleted from font path.
[ 3619.255] (WW) The directory "/usr/share/fonts/X11/100dpi" does not exist.
[ 3619.255] Entry deleted from font path.
[ 3619.255] (WW) The directory "/usr/share/fonts/X11/75dpi" does not exist.
[ 3619.255] Entry deleted from font path.
[ 3619.255] (==) FontPath set to:
/usr/share/fonts/X11/misc,
/usr/share/fonts/X11/Type1,
built-ins
[ 3619.255] (==) ModulePath set to "/usr/lib/x86_64-linux-gnu/xorg/extra-modules,/usr/lib/xorg/extra-modules,/usr/lib/xorg/modules"
[ 3619.255] (II) Loader magic: 0x560254c98e00
[ 3619.255] (II) Module ABI versions:
[ 3619.255] X.Org ANSI C Emulation: 0.4
[ 3619.255] X.Org Video Driver: 23.0
[ 3619.255] X.Org XInput driver : 24.1
[ 3619.255] X.Org Server Extension : 10.0
[ 3619.259] (II) systemd-logind: took control of session /org/freedesktop/login1/session/c8
[ 3619.260] (II) xfree86: Adding drm device (/dev/dri/card0)
[ 3619.260] (EE) systemd-logind: failed to take device /dev/dri/card0: Operation not permitted
[ 3619.260] (EE) /dev/dri/card0: failed to set DRM interface version 1.4: Permission denied
[ 3619.267] (--) PCI:*(0:3:0:0) 10de:13ba:10de:1097 rev 162, Mem @ 0xd2000000/16777216, 0xc0000000/268435456, 0xd0000000/33554432, I/O @ 0x00005000/128, BIOS @ 0x????????/131072
[ 3619.267] (II) "glx" will be loaded. This was enabled by default and also specified in the config file.
[ 3619.267] (II) LoadModule: "dbe"
[ 3619.267] (II) Module "dbe" already built-in
[ 3619.267] (II) LoadModule: "ddc"
[ 3619.267] (II) Module "ddc" already built-in
[ 3619.267] (II) LoadModule: "extmod"
[ 3619.267] (II) Module "extmod" already built-in
[ 3619.267] (II) LoadModule: "glx"
[ 3619.267] (II) Loading /usr/lib/xorg/modules/extensions/libglx.so
[ 3619.268] (II) Module glx: vendor="X.Org Foundation"
[ 3619.268] compiled for 1.19.3, module version = 1.0.0
[ 3619.268] ABI class: X.Org Server Extension, version 10.0
[ 3619.269] (II) LoadModule: "int10"
[ 3619.269] (II) Loading /usr/lib/xorg/modules/libint10.so
[ 3619.269] (II) Module int10: vendor="X.Org Foundation"
[ 3619.269] compiled for 1.19.3, module version = 1.0.0
[ 3619.269] ABI class: X.Org Video Driver, version 23.0
[ 3619.269] (II) LoadModule: "record"
[ 3619.269] (II) Module "record" already built-in
[ 3619.269] (II) LoadModule: "vbe"
[ 3619.269] (II) Loading /usr/lib/xorg/modules/libvbe.so
[ 3619.269] (II) Module vbe: vendor="X.Org Foundation"
[ 3619.269] compiled for 1.19.3, module version = 1.1.0
[ 3619.269] ABI class: X.Org Video Driver, version 23.0
[ 3619.269] (II) LoadModule: "xorgxrdp"
[ 3619.269] (II) Loading /usr/lib/xorg/modules/libxorgxrdp.so
[ 3619.269] (II) Module XORGXRDP: vendor="X.Org Foundation"
[ 3619.269] compiled for 1.18.4, module version = 1.0.0
[ 3619.270] ABI class: X.Org Video Driver, version 20.0
[ 3619.270] (EE) xorgxrdp: module ABI major version (20) doesn't match the server's version (23)
[ 3619.270] (II) UnloadModule: "xorgxrdp"
[ 3619.270] (II) Unloading xorgxrdp
[ 3619.270] (EE) Failed to load module "xorgxrdp" (module requirement mismatch, 0)
[ 3619.270] (II) LoadModule: "fb"
[ 3619.270] (II) Loading /usr/lib/xorg/modules/libfb.so
[ 3619.270] (II) Module fb: vendor="X.Org Foundation"
[ 3619.270] compiled for 1.19.3, module version = 1.0.0
[ 3619.270] ABI class: X.Org ANSI C Emulation, version 0.4
[ 3619.270] (II) LoadModule: "xrdpdev"
[ 3619.270] (II) Loading /usr/lib/xorg/modules/drivers/xrdpdev_drv.so
[ 3619.270] (EE) Failed to load /usr/lib/xorg/modules/drivers/xrdpdev_drv.so: /usr/lib/xorg/modules/drivers/xrdpdev_drv.so: undefined symbol: rdpRRModeDestroy
[ 3619.270] (II) UnloadModule: "xrdpdev"
[ 3619.270] (II) Unloading xrdpdev
[ 3619.270] (EE) Failed to load module "xrdpdev" (loader failed, 7)
[ 3619.270] (==) Matched nvidia as autoconfigured driver 0
[ 3619.270] (==) Matched nouveau as autoconfigured driver 1
[ 3619.270] (==) Matched modesetting as autoconfigured driver 2
[ 3619.270] (==) Matched fbdev as autoconfigured driver 3
[ 3619.270] (==) Matched vesa as autoconfigured driver 4
[ 3619.270] (==) Assigned the driver to the xf86ConfigLayout
[ 3619.270] (II) LoadModule: "nvidia"
[ 3619.271] (WW) Warning, couldn't open module nvidia
[ 3619.271] (II) UnloadModule: "nvidia"
[ 3619.271] (II) Unloading nvidia
[ 3619.271] (EE) Failed to load module "nvidia" (module does not exist, 0)
[ 3619.271] (II) LoadModule: "nouveau"
[ 3619.271] (II) Loading /usr/lib/xorg/modules/drivers/nouveau_drv.so
[ 3619.271] (II) Module nouveau: vendor="X.Org Foundation"
[ 3619.271] compiled for 1.19.3, module version = 1.0.14
[ 3619.271] Module class: X.Org Video Driver
[ 3619.271] ABI class: X.Org Video Driver, version 23.0
[ 3619.271] (II) LoadModule: "modesetting"
[ 3619.271] (II) Loading /usr/lib/xorg/modules/drivers/modesetting_drv.so
[ 3619.271] (II) Module modesetting: vendor="X.Org Foundation"
[ 3619.271] compiled for 1.19.3, module version = 1.19.3
[ 3619.271] Module class: X.Org Video Driver
[ 3619.271] ABI class: X.Org Video Driver, version 23.0
[ 3619.271] (II) LoadModule: "fbdev"
[ 3619.272] (II) Loading /usr/lib/xorg/modules/drivers/fbdev_drv.so
[ 3619.272] (II) Module fbdev: vendor="X.Org Foundation"
[ 3619.272] compiled for 1.19.3, module version = 0.4.4
[ 3619.272] Module class: X.Org Video Driver
[ 3619.272] ABI class: X.Org Video Driver, version 23.0
[ 3619.272] (II) LoadModule: "vesa"
[ 3619.272] (II) Loading /usr/lib/xorg/modules/drivers/vesa_drv.so
[ 3619.272] (II) Module vesa: vendor="X.Org Foundation"
[ 3619.272] compiled for 1.19.3, module version = 2.3.4
[ 3619.272] Module class: X.Org Video Driver
[ 3619.272] ABI class: X.Org Video Driver, version 23.0
[ 3619.272] (II) LoadModule: "xrdpmouse"
[ 3619.272] (II) Loading /usr/lib/xorg/modules/input/xrdpmouse_drv.so
[ 3619.272] (II) Module XRDPMOUSE: vendor="X.Org Foundation"
[ 3619.272] compiled for 1.18.4, module version = 1.0.0
[ 3619.272] Module class: X.Org XInput Driver
[ 3619.272] ABI class: X.Org XInput driver, version 22.1
[ 3619.272] (EE) xrdpmouse: module ABI major version (22) doesn't match the server's version (24)
[ 3619.272] (II) UnloadModule: "xrdpmouse"
[ 3619.272] (II) Unloading xrdpmouse
[ 3619.272] (EE) Failed to load module "xrdpmouse" (module requirement mismatch, 0)
[ 3619.272] (II) LoadModule: "xrdpkeyb"
[ 3619.273] (II) Loading /usr/lib/xorg/modules/input/xrdpkeyb_drv.so
[ 3619.273] (II) Module XRDPKEYB: vendor="X.Org Foundation"
[ 3619.273] compiled for 1.18.4, module version = 1.0.0
[ 3619.273] Module class: X.Org XInput Driver
[ 3619.273] ABI class: X.Org XInput driver, version 22.1
[ 3619.273] (EE) xrdpkeyb: module ABI major version (22) doesn't match the server's version (24)
[ 3619.273] (II) UnloadModule: "xrdpkeyb"
[ 3619.273] (II) Unloading xrdpkeyb
[ 3619.273] (EE) Failed to load module "xrdpkeyb" (module requirement mismatch, 0)
[ 3619.273] (II) NOUVEAU driver Date: Tue Mar 7 18:44:43 2017 -0500
[ 3619.273] (II) NOUVEAU driver for NVIDIA chipset families :
[ 3619.273] RIVA TNT (NV04)
[ 3619.273] RIVA TNT2 (NV05)
[ 3619.273] GeForce 256 (NV10)
[ 3619.273] GeForce 2 (NV11, NV15)
[ 3619.273] GeForce 4MX (NV17, NV18)
[ 3619.273] GeForce 3 (NV20)
[ 3619.273] GeForce 4Ti (NV25, NV28)
[ 3619.273] GeForce FX (NV3x)
[ 3619.273] GeForce 6 (NV4x)
[ 3619.273] GeForce 7 (G7x)
[ 3619.273] GeForce 8 (G8x)
[ 3619.273] GeForce GTX 200 (NVA0)
[ 3619.273] GeForce GTX 400 (NVC0)
[ 3619.273] (II) modesetting: Driver for Modesetting Kernel Drivers: kms
[ 3619.273] (II) FBDEV: driver for framebuffer: fbdev
[ 3619.273] (II) VESA: driver for VESA chipsets: vesa
[ 3619.273] (EE)
Fatal server error:
[ 3619.273] (EE) parse_vt_settings: Cannot open /dev/tty0 (Permission denied)
[ 3619.273] (EE)
[ 3619.273] (EE)
Please consult the The X.Org Foundation support
at http://wiki.x.org
for help.
[ 3619.273] (EE) Please also check the log file at ".xorgxrdp.10.log" for additional information.
[ 3619.273] (EE)
[ 3619.273] (WW) xf86CloseConsole: KDSETMODE failed: Bad file descriptor
[ 3619.273] (WW) xf86CloseConsole: VT_GETMODE failed: Bad file descriptor
[ 3619.274] (EE) Server terminated with error (1). Closing log file.
zertrin
on 15 Aug 2017
I see many cases of ABI mismatch:
xorgxrdp: module ABI major version (20) doesn't match the server's version (23)
xrdpmouse: module ABI major version (22) doesn't match the server's version (24)
xrdpkeyb: module ABI major version (22) doesn't match the server's version (24)
How to overcome that?
zertrin
on 15 Aug 2017
Ok I have found a workaround that _"works for me ©"_ for now: I downgrade xserver-xorg-core to the previous version (1.18). (note that I am compiling the latest git version of xrdp and xorgxrdp with the fix concerning the libxfont mentioned in my previous comment: https://github.com/neutrinolabs/xrdp/issues/786#issuecomment-322379342 )
I spent too much time to figure out how to do it on Ubuntu 16.04 so I'll share with you:
_DISCLAIMER: It worked for me, it may break everything for you, I take no responsibility, use at your own risk. (or maybe it works for you too, or maybe not... well life is like a box of chocolate...)_
Step 1: add the old-releases Ubuntu repository (because old versions of the packages are not available in the default repositories... only the last one)
Step 2: for some reason, the -hwe packages for xorg didn't work even when downgrading from 1.19 to 1.18, so I finally got rid of the HWE version to install the non HWE versions:
(I did it with help of aptitude to do it all at once)
- remove
xserver-xorg-core-hwe-16.04:amd64 (2:1.19.3-1ubuntu1~16.04.2) - remove
xserver-xorg-input-all-hwe-16.04:amd64 (1:7.7+16ubuntu3~16.04.1) - remove
xserver-xorg-video-all-hwe-16.04:amd64 (1:7.7+16ubuntu3~16.04.1) - install
xserver-xorg-core:amd64 (2:1.18.4-0ubuntu0.3) - install
xserver-xorg-input-all:amd64 (1:7.7+13ubuntu3) - install
xserver-xorg-video-all:amd64 (1:7.7+13ubuntu3)
(xserver-common should normally stay at version 2:1.18.4-0ubuntu0.3)
_Good luck if you are trying this._
In the end my packages' versions look like that:
for xserver-xorg-* :
hi xserver-xorg-core 2:1.18.4-0ubuntu0.3
hi xserver-xorg-dev 2:1.18.4-0ubuntu0.3
hi xserver-xorg-input-all 1:7.7+13ubuntu3
hi xserver-xorg-video-all 1:7.7+13ubuntu3
(you can see that I have set these version on Hold in apt so that they don't get upgraded automatically next time)
just for completeness, for compiling xorgxrdp:
ii libxfont-dev 1:2.0.1-3~ubuntu16.04.1
ii libxfont1:amd64 1:1.5.1-1ubuntu0.16.04.2
ii libxfont1-dev 1:1.5.1-1ubuntu0.16.04.2
ii libxfont2:amd64 1:2.0.1-3~ubuntu16.04.1
(note that the version 1:1.5.1-1ubuntu0.16.04.2 for libxfont1 and libxfont1-dev is only available in the xenial-proposed repository for now)
After rebooting it worked again for me (using mate-session).
_(well to be honest, that's an oversimplification since I didn't find the correct solution on the first try, or the second, ... welll I guess I have rebooted like 10 times with different combinations of packages. So this summary was not really tested directly as is. I hope I didn't forgot something essential, but there are chances I did miss something. Hopefully this will still be of help for someone else.)_
EDIT: and no this isn't a solution for this GitHub issue, only a _workaround_ to be able to work again with remote desktop sessions until the root cause is fixed. My best guess for now is the ABI incompatibility problem, but in reality I have absolutely no clue how this whole xrdp/xorg magic works. Thanks dear developer to provide such a useful software in the first place :heart: :heart: :heart:
zertrin
on 15 Aug 2017
Well, I'm x-confused as ever. Arrgh.
jerryhall
on 29 Aug 2017
I updated the packages in xubuntu 16.04 and got exactly such a problem, is there a solution except downgrade xserver-xorg-core?
DS455
on 30 Aug 2017
Now xorgxrdp should be built properly as ubuntu fix has been committed.
https://bugs.launchpad.net/ubuntu/+source/libxfont/+bug/1707691
metalefty
on 30 Aug 2017
Yes it builds, but still doesn't solve the abi problem that requires a downgrade of xorg.
The libxfont issue was only a bump in the road while troubleshooting this issue, but not related to the black screen problem.
zertrin
on 30 Aug 2017
It worked for me. Ubuntu 16.04 LTS, no ABI problem.
~
xserver-xorg-core 2:1.18.4-0ubuntu0.3
libxfont1-dev 1:1.5.1-1ubuntu0.16.04.2
~
Xorg :10 -config xrdp/xorg.conf shows no ABI error.
metalefty
on 31 Aug 2017
Yes with the xorg version you mentioned this works, but for Desktop installs with standard updates of Ubuntu, the version of xorg I had after the most recent Ubuntu LTS upgrade was xserver-xorg-core-hwe-16.04:amd64 (2:1.19.3-1ubuntu1~16.04.2), which doesn't work.
As already mentioned in previous comments*, _the issue started when performing a standard upgrade of Ubuntu to 16.04.2 which included the aforementioned upgrade of xserver-xorg-core_.
The workaround I gave above was indeed to force revert to xserver-xorg-core 2:1.18.4-0ubuntu0.3, which isn't anymore in the standard repositories in case you already upgraded to 16.04.2. Thus the need to add the old-releases repository which shouldn't be done in general.
*:
Same issue here, Ubuntu 16.04, just installed the latest LTS updates and got the black screen.
zertrin
on 31 Aug 2017
OK, I understand you and I confirmed the ABI error. I'll investigate it. Let's create a new issue on xorgxrdp repo and discuss about the ABI error on Ubuntu 16.04 in a separate issue.
That is xorgxrdp issue rather than xrdp.
metalefty
on 31 Aug 2017
@zertrin xorgxrdp must be built with xserver 1.19 if you want to run xorgxrdp with xserver 1.19. Please sync xserver versions when being built and being run. Meaning, if you want to use -hwe-16.04 suffixed packages, -dev packages also need to be -hwe-16.04 suffixed. Make sure xserver-xorg-dev uninstalled and xserver-xorg-dev-hwe-16.04 installed.
$ dpkg -la |grep xserver-xorg
ii xserver-xorg-core-hwe-16.04 2:1.19.3-1ubuntu1~16.04.2 amd64 Xorg X server - core server
ii xserver-xorg-dev-hwe-16.04 2:1.19.3-1ubuntu1~16.04.2 amd64 Xorg X server - development files
Now I get no ABI errors with xserver 1.19 (xserver-xorg-hwe-16.04). Working fine for me.
$ Xorg :10 -config xrdp/xorg.conf
X.Org X Server 1.19.3
Release Date: 2017-03-15
X Protocol Version 11, Revision 0
Build Operating System: Linux 4.4.0-87-generic x86_64 Ubuntu
Current Operating System: Linux ip-10-100-101-254 4.4.0-1022-aws #31-Ubuntu SMP Tue Jun 27 11:27:55 UTC 2017 x86_64
Kernel command line: BOOT_IMAGE=/boot/vmlinuz-4.4.0-1022-aws root=LABEL=cloudimg-rootfs ro console=tty1 console=ttyS0
Build Date: 25 July 2017 01:30:08PM
xorg-server 2:1.19.3-1ubuntu1~16.04.2 (For technical support please see http://www.ubuntu.com/support)
Current version of pixman: 0.33.6
Before reporting problems, check http://wiki.x.org
to make sure that you have the latest version.
Markers: (--) probed, (**) from config file, (==) default setting,
(++) from command line, (!!) notice, (II) informational,
(WW) warning, (EE) error, (NI) not implemented, (??) unknown.
(==) Log file: "/home/ubuntu/.local/share/xorg/Xorg.10.log", Time: Thu Aug 31 03:24:19 2017
(++) Using config file: "/etc/X11/xrdp/xorg.conf"
(snip)
@DS455 this will help you, too.
metalefty
on 31 Aug 2017
@metalefty
Many thanks! You are a true friend! Worked!
DS455
on 31 Aug 2017
I will not be able to test myself before the next maintenance window for the server where I had this problem (i.e. not soon), but indeed the solution makes sense 🤦 and I _guess_ is should work.
zertrin
on 31 Aug 2017
@johnarnold how's it going? it should work for you now.
metalefty
on 1 Sep 2017
If you disconnect from the terminal server and you try to connect again, the connection does not occur.
xrdp-sesman.log:
[20170913-08:37:52] [INFO ] A connection received from 127.0.0.1 port 36100
[20170913-08:37:52] [INFO ] ++ reconnected session: username r2d2, display :33.0, session_pid 3926, ip 192.168.0.27:47518 - socket: 12
[20170913-08:37:53] [DEBUG] Closed socket 8 (AF_INET 127.0.0.1:3350)
xrdp.log:
[20170913-08:37:52] [DEBUG] xrdp_wm_log_msg: connecting to sesman ip 127.0.0.1 port 3350
[20170913-08:37:52] [INFO ] xrdp_wm_log_msg: sesman connect ok
[20170913-08:37:52] [DEBUG] xrdp_wm_log_msg: sending login info to session manager, please wait...
[20170913-08:37:52] [DEBUG] return value from xrdp_mm_connect 0
[20170913-08:37:53] [INFO ] xrdp_wm_log_msg: login successful for display 33
[20170913-08:37:53] [DEBUG] xrdp_wm_log_msg: started connecting
[20170913-08:37:56] [DEBUG] Closed socket 19 (AF_UNIX)
[20170913-08:38:00] [DEBUG] Closed socket 19 (AF_UNIX)
[20170913-08:38:04] [DEBUG] Closed socket 19 (AF_UNIX)
[20170913-08:38:07] [DEBUG] Closed socket 19 (AF_UNIX)
[20170913-08:38:11] [DEBUG] Closed socket 19 (AF_UNIX)
[20170913-08:38:14] [DEBUG] Closed socket 19 (AF_UNIX)
[20170913-08:38:18] [DEBUG] Closed socket 19 (AF_UNIX)
[20170913-08:38:21] [DEBUG] Closed socket 19 (AF_UNIX)
[20170913-08:38:25] [DEBUG] Closed socket 19 (AF_UNIX)
[20170913-08:38:28] [DEBUG] Closed socket 19 (AF_UNIX)
[20170913-08:38:32] [DEBUG] Closed socket 19 (AF_UNIX)
[20170913-08:38:36] [DEBUG] Closed socket 19 (AF_UNIX)
[20170913-08:38:39] [DEBUG] Closed socket 19 (AF_UNIX)
[20170913-08:38:43] [DEBUG] Closed socket 19 (AF_UNIX)
[20170913-08:38:46] [DEBUG] Closed socket 19 (AF_UNIX)
[20170913-08:38:50] [DEBUG] Closed socket 19 (AF_UNIX)
[20170913-08:38:54] [DEBUG] Closed socket 19 (AF_UNIX)
[20170913-08:38:57] [DEBUG] Closed socket 19 (AF_UNIX)
[20170913-08:39:01] [DEBUG] Closed socket 19 (AF_UNIX)
[20170913-08:39:04] [DEBUG] Closed socket 19 (AF_UNIX)
[20170913-08:39:08] [DEBUG] Closed socket 19 (AF_UNIX)
[20170913-08:39:11] [DEBUG] Closed socket 19 (AF_UNIX)
[20170913-08:39:15] [DEBUG] Closed socket 19 (AF_UNIX)
[20170913-08:39:18] [DEBUG] Closed socket 19 (AF_UNIX)
[20170913-08:39:22] [DEBUG] Closed socket 19 (AF_UNIX)
[20170913-08:39:26] [DEBUG] Closed socket 19 (AF_UNIX)
[20170913-08:39:29] [DEBUG] Closed socket 19 (AF_UNIX)
[20170913-08:39:33] [DEBUG] Closed socket 19 (AF_UNIX)
[20170913-08:39:36] [DEBUG] Closed socket 19 (AF_UNIX)
[20170913-08:39:40] [DEBUG] Closed socket 19 (AF_UNIX)
[20170913-08:39:43] [DEBUG] Closed socket 19 (AF_UNIX)
[20170913-08:39:47] [DEBUG] Closed socket 19 (AF_UNIX)
[20170913-08:39:50] [DEBUG] Closed socket 19 (AF_UNIX)
[20170913-08:39:54] [DEBUG] Closed socket 19 (AF_UNIX)
[20170913-08:39:58] [DEBUG] Closed socket 19 (AF_UNIX)
[20170913-08:40:01] [DEBUG] Closed socket 19 (AF_UNIX)
[20170913-08:40:05] [DEBUG] Closed socket 19 (AF_UNIX)
[20170913-08:40:08] [DEBUG] Closed socket 19 (AF_UNIX)
[20170913-08:40:12] [DEBUG] Closed socket 19 (AF_UNIX)
[20170913-08:40:15] [DEBUG] Closed socket 19 (AF_UNIX)
[20170913-08:40:19] [DEBUG] Closed socket 19 (AF_UNIX)
[20170913-08:40:22] [DEBUG] Closed socket 19 (AF_UNIX)
[20170913-08:40:26] [DEBUG] Closed socket 19 (AF_UNIX)
[20170913-08:40:30] [DEBUG] Closed socket 19 (AF_UNIX)
[20170913-08:40:33] [DEBUG] Closed socket 19 (AF_UNIX)
[20170913-08:40:37] [DEBUG] Closed socket 19 (AF_UNIX)
[20170913-08:40:40] [DEBUG] Closed socket 19 (AF_UNIX)
[20170913-08:40:44] [DEBUG] Closed socket 19 (AF_UNIX)
[20170913-08:40:47] [DEBUG] Closed socket 19 (AF_UNIX)
[20170913-08:40:51] [DEBUG] Closed socket 19 (AF_UNIX)
[20170913-08:40:54] [DEBUG] Closed socket 19 (AF_UNIX)
[20170913-08:40:58] [DEBUG] Closed socket 19 (AF_UNIX)
[20170913-08:41:01] [DEBUG] Closed socket 19 (AF_UNIX)
[20170913-08:41:05] [DEBUG] Closed socket 19 (AF_UNIX)
[20170913-08:41:09] [DEBUG] Closed socket 19 (AF_UNIX)
[20170913-08:41:12] [DEBUG] Closed socket 19 (AF_UNIX)
[20170913-08:41:16] [DEBUG] Closed socket 19 (AF_UNIX)
[20170913-08:41:19] [DEBUG] Closed socket 19 (AF_UNIX)
[20170913-08:41:23] [DEBUG] Closed socket 19 (AF_UNIX)
[20170913-08:41:26] [DEBUG] xrdp_wm_log_msg: connection problem, giving up
[20170913-08:41:26] [DEBUG] Closed socket 19 (AF_UNIX)
[20170913-08:41:26] [DEBUG] xrdp_wm_log_msg: some problem
[20170913-08:41:26] [DEBUG] xrdp_mm_module_cleanup
[20170913-08:41:26] [DEBUG] Closed socket 18 (AF_INET 127.0.0.1:36100)
After some time this command helps:
sudo pkill -9 -u r2d2
Is it possible to fix this?
DS455
on 13 Sep 2017
This problem user in the system weighs 2 processes reconnectwm.sh, they can not be killed.
DS455
on 13 Sep 2017
[20170913-08:37:52] [INFO ] ++ reconnected session: username r2d2, display :33.0, session_pid 3926, ip 192.168.0.27:47518 - socket: 12
display:33 in the /tmp/.xrdp folder does not appear.
DS455
on 13 Sep 2017
Hello, just sharing my log file
It starts when I start the two services, and it ends right after I click ok on the error dialog that eventually pops up on the connecting client (takes about 5 minutes to pop up)
Nothing about the nature of the problem has changed, just hoping my log file of the newest devel branch will help shed some light on my issue.
Thanks
AeliusSaionji
on 21 Sep 2017
The issue is solved for the reporter, closing. The root cause of this issue is xorgxrdp is not properly built and installed for the reporter. To whom have blank screen with different causes, please raise your own issue.
metalefty
on 2 Oct 2017
I'm still getting this error in Ubuntu 20.04 - blank screen - no other significant errors in the logs.
dioptre
on 18 Jun 2020
I'm still getting this error in Ubuntu 20.04 - blank screen - no other significant errors in the logs.
I am found the solution. To fix this issue install package xorgxrdp.
(sudo apt install xorgxrdp)
May be developers must to add the package xorgxrdp to dependencies.
PRIHLOP
on 12 Dec 2020
Related issues
jsorg71
·
7Comments
Rubarius
·
5Comments
AlexNikolaenko
·
3Comments
donkey
·
6Comments
Kaydub00
·
8Comments
Most helpful comment
@zertrin xorgxrdp must be built with xserver 1.19 if you want to run xorgxrdp with xserver 1.19. Please sync xserver versions when being built and being run. Meaning, if you want to use
-hwe-16.04suffixed packages,-devpackages also need to be-hwe-16.04suffixed. Make surexserver-xorg-devuninstalled andxserver-xorg-dev-hwe-16.04installed.Now I get no ABI errors with xserver 1.19 (xserver-xorg-hwe-16.04). Working fine for me.
