Trix: add file attachment in toolbar and custom preview

[trheyi]

I try to add file attachment icon in toolbar and custom preview, it spent my lots time to find the solution. share my solution at here, hope it's useful for you .

1. add attachment icon to toolbar.

Javascript

        let toolBar = trix.toolbarElement;
        let spacer = toolBar.querySelector(".trix-button-group-spacer");
        let dialogElm = toolBar.querySelector(".trix-dialogs");

       // add a new block
        let blockElm = document.createElement("span");
            blockElm.setAttribute("class","trix-button-group trix-button-group--block-tools trix-button-group-custom");
            blockElm.setAttribute("data-trix-button-group", "block-tools");

          let trixId = trix.trixId;

        let buttonContent = `
            <button type="button"
                class="trix-button trix-button--icon trix-button--icon-attach"
                data-trix-attribute="attach"
                data-trix-key="+" title="附件" tabindex="-1"></button>
        `;

        let dialogContent = `
            <div class="trix-dialog trix-dialog--attach" data-trix-dialog="attach" data-trix-dialog-attribute="attach"  >
                <div class="trix-dialog__attach-fields">
                    <input type="file" class="trix-input trix-input--dialog" >
                    <div class="trix-button-group">
                        <input type="button" class="trix-button trix-button--dialog"
                            onclick="
                                var trix = document.querySelector('trix-editor[trix-id=\\'${trixId}\\']');
                                var fileElm = this.parentElement.parentElement.querySelector('input[type=\\'file\\']');
                                if ( fileElm.files.length == 0 ) {
                                    console.log('nothing selected');
                                    return;
                                }
                                var file = fileElm.files[0];
                                trix.editor.insertFile(file);
                            ";
                            value="插入附件" data-trix-method="removeAttribute"
                        >
                        <input type="button" class="trix-button trix-button--dialog" value="取消操作" data-trix-method="removeAttribute">
                    </div>
                </div>
            </div>
        `;
        // add attach icon button
        blockElm.insertAdjacentHTML("beforeend", buttonContent);
        // add dialog
        dialogElm.insertAdjacentHTML("beforeend", dialogContent);

css

.trix-button--icon-attach::before {
}

2. custom preview.

use attachment content filed to set attachment preview template.
( attachment upload see : https://trix-editor.org/js/attachments.js )

Javascript

let url = "your remote url "
/**
 *  on trix-attachment-add upload file to remote server
 */
elm.addEventListener("trix-attachment-add", (event) => {
           uploadFile(event.attachment), setProgress, setAttributes)
            function setProgress(progress) {
              attachment.setUploadProgress(progress)
            }

            function setAttributes(data) {
              console.log(attachment);
            }
});

function uploadFile(attachment, progressCallback, successCallback) {

            // Check File
            let file = attachment.file;

            var key = createStorageKey(file)
            var formData = createFormData(key, file)
            var xhr = new XMLHttpRequest()

            xhr.open("POST", url, true)

            xhr.upload.addEventListener("progress", function(event) {
                var progress = event.loaded / event.total * 100
                progressCallback(progress)
            })

            xhr.addEventListener("load", function(event) {
                let response = {};
                try {
                    response = JSON.parse( xhr.responseText );
                }catch( e ){
                    console.log('upload error');
                    attachment.remove();
                    return;
                }

                // failure
                if ( response.code != 0 || typeof response.data != "object" ) {
                    let message = response.message || "上传失败";
                    attachment.remove();
                    console.log( message );
                    return;
                }


                let data = response.data || {};
                setContent( attachment, data);
                successCallback(data);
            })

            xhr.send(formData);
        }

/**
 *  @param object attachment  struct of  attachment
 *  @param object data  remote server response data after upload.
 */
function setContent( attachment, data ) {

            let file = attachment.file;
            let attributes ={
                previewable: false,
                url: data.url,
                href: data.url
            };

            if (!data.mime ){
                data.mime = "application/file";
            }

            if ( data.mime.includes("image") ) { // image
                attributes["content"] = `
                    <span class="trix-preview-image" data-url="${data.url}"  data-name="${file.name}" >
                        <img src="${data.url}" />
                    <span>
                `;

            } else if ( data.mime.includes("video") ) { // video
                attributes["content"] = `
                    <span class="trix-preview-video"  data-url="${data.url}"  data-name="${file.name}" >
                        <video width="100%" height="auto" controls>
                            <source src="${data.url}" type="${data.mime}">
                        </video>
                    <span>
                `;

            } else {  // other
                attributes["content"] = `
                    <span class="trix-preview-file" data-url="${data.url}"  data-name="${file.name}" >
                        ${file.name}
                    <span>
                `;
            }

            attachment.setAttributes(attributes);
        }

css

.trix-preview-file {
  border: 1px solid red;
}

.trix-preview-video {
  border: 1px solid yellow;
}

.trix-preview-image {
  border: 1px solid green;
}

[lucascaton]

It'd be nice to have it merged into Trix codebase! 🙂

[George-Miao]

Hope it can merge :) It's really nice

[PandaWhisperer]

This doesn't seem to work for me. It says ReferenceError: trix is not defined in the console. This makes sense, because when I look through the Trix source, everything is stored under Trix, not trix.

I tried changing the code accordingly, but it turns out that Trix.toolbarElement also does not exist, and neither does Trix.trixId. Was this written for an older version of the code?

EDIT: turns out there is only a small piece of code missing to make this work:

let trix = document.querySelector("trix-editor");

All the required attributes are defined on that.

[PandaWhisperer]

Alright, after an hour or so I've managed to complete the code so that it can just be dropped into a project and should work right away. I also translated the button labels to English, and fixed the CSS for the dialog. Instead of making a new button group, I am adding the button just next to the "link" button.

JavaScript

document.addEventListener('trix-initialize', function(e) {
  let editor  = e.target;
  let toolbar = editor.toolbarElement;
  let ttools  = toolbar.querySelector(".trix-button-group--text-tools");
  let dialogs = toolbar.querySelector(".trix-dialogs");
  let trixId  = editor.trixId;

  let buttonContent = `
    <button type="button"
      class="trix-button trix-button--icon trix-button--icon-attach"
      data-trix-attribute="attach"
      data-trix-key="+" title="Attach file" tabindex="-1">
    </button>
  `;

  let dialogContent = `
    <div class="trix-dialog trix-dialog--attach" data-trix-dialog="attach" data-trix-dialog-attribute="attach">
      <div class="trix-dialog__attach-fields">
        <input type="file" class="trix-input trix-input--dialog">
        <div class="trix-button-group">
          <input type="button" class="trix-button trix-button--dialog"
            onclick="
              var trix = document.querySelector('trix-editor[trix-id=\\'${trixId}\\']');
              var fileElm = this.parentElement.parentElement.querySelector('input[type=\\'file\\']');
              if ( fileElm.files.length == 0 ) {
                console.log('nothing selected');
                return;
              }
              var file = fileElm.files[0];
              trix.editor.insertFile(file);
            "
            value="Attach" data-trix-method="removeAttribute">
          <input type="button" class="trix-button trix-button--dialog" value="Cancel" data-trix-method="removeAttribute">
        </div>
      </div>
    </div>
  `;
  // add attach icon button
  ttools.insertAdjacentHTML("beforeend", buttonContent);
  // add dialog
  dialogs.insertAdjacentHTML("beforeend", dialogContent);
});

CSS

.trix-button--icon-attach::before {
}

trix-toolbar .trix-dialog--attach {
  max-width: 600px;
}

trix-toolbar .trix-dialog__attach-fields {
  display: flex;
  align-items: baseline;
}

trix-toolbar .trix-dialog__attach-fields .trix-input {
  flex: 1;
}

trix-toolbar .trix-dialog__attach-fields .trix-button-group {
  flex: 0 0 content;
  margin: 0;
}

Thanks to @trheyi for posting the original version, without his work, this would have taken much longer.

[DanielHeath]

@PandaWhisperer nice!

The rest of trix is using Trix.config.lang for button labels, enabling internationalized use. I'd guess the best approach for a plugin would be something like:

Trix.config.lang.filePreview ||= {};
Trix.config.lang.filePreview.attach ||= "Attach";

That way, if custom translations have been specified they won't get overridden by defaults.

[PandaWhisperer]

Thanks @DanielHeath. I'll try to make a version that's integrated with with Trix when I have time.

[PandaWhisperer]

Alright. I think I got the correct code for the attachment feature, but #616 is currently blocking me from testing it. Help please?

[juansecaro]

Does the current version have this feature? It seems it's only drag & drop so far..

[nyrf]

Thanks, it saves my times.

[Sushma-tiwari]

I need preview for .pdf attachment upload in trix basecamp.
