Rocket.chat: Grafana Web Integration Via Slack Broken

Created on 19 Jul 2018 · 11Comments · Source: RocketChat/Rocket.Chat

Description:

Upon creating a notification channel in Grafana using the Slack channel, sending any notification over error are reported in Rocket Chat

Steps to reproduce:

Create notification channel using Slack in Grafana and send notification
Check for errors in Rocket Chat Logs

Expected behavior:

Messages are displayed within the configured chat room

Actual behavior:

The following log is displayed;

Jul 19 14:28:45  rocketchat: #033[34mIntegrations ➔ Incoming WebHook.info#033[39m Post integration: localhost - Grafana
Jul 19 14:28:45  rocketchat: #033[34mIntegrations ➔ Incoming WebHook.debug#033[39m @urlParams: { integrationId: 'xxxxxxxxxxxx',
Jul 19 14:28:45  rocketchat: token: 'xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx' }
Jul 19 14:28:45  rocketchat: #033[34mIntegrations ➔ Incoming WebHook.debug#033[39m @bodyParams: { attachments:
Jul 19 14:28:45  rocketchat: [ { color: '#D63232',
Jul 19 14:28:45  rocketchat: fallback: '[Alerting] Test notification',
Jul 19 14:28:45  rocketchat: fields: [Array],
Jul 19 14:28:45  rocketchat: footer: 'Grafana v5.2.1',
Jul 19 14:28:45  rocketchat: footer_icon: 'https://grafana.com/assets/img/fav32.png',
Jul 19 14:28:45  rocketchat: image_url: '',
Jul 19 14:28:45  rocketchat: text: '@all Someone is testing the alert notification within grafana.',
Jul 19 14:28:45  rocketchat: title: '[Alerting] Test notification',
Jul 19 14:28:45  rocketchat: title_link: 'http://localhost/',
Jul 19 14:28:45  rocketchat: ts: 1532010525 } ],
Jul 19 14:28:45  rocketchat: channel: '#critical-alerts',
Jul 19 14:28:45  rocketchat: parse: 'full' }
Jul 19 14:28:45  rocketchat: #033[34mAPI ➔ debug#033[39m Failure { statusCode: 400,
Jul 19 14:28:45  rocketchat: body:
Jul 19 14:28:45  rocketchat: { success: false,
Jul 19 14:28:45  rocketchat: error: 'Match error: Match error: Expected string, got number in field value' } }

Server Setup Information:

Version of Rocket.Chat Server: 0.66.3
Operating System: Centos 7.5
Deployment Method: tar
Number of Running Instances: 1
DB Replicaset Oplog:
NodeJS Version: v8.9.3
MongoDB Version: 2.6.12

webhooks bug

Source

APenketh

👍3

Most helpful comment

As a temporary workaround, you can use a manually applied script:

class Script {

    process_incoming_request({ request }) {

        request.content.attachments.forEach(function (attachment) {
            attachment.fields.forEach(function (field) {
                field.value = field.value.toString();
            });
        });

        return request;

    }
}

makubi on 24 Jul 2018

👍4 ❤1 🎉1

All 11 comments

same here

thereapman on 19 Jul 2018

Same issue, worked on 0.5x releases (plus Grafana 4x).
I updated both rocketchat to last 0.66 and Grafana to 5.2.1. Not sure if something has changed on Grafana side

I receive this same error:
rocketchat: error: 'Match error: Match error: Expected string, got number in field value' } }

hugodopradofernandes on 20 Jul 2018

APenketh on 20 Jul 2018

Seams to be more on the RocketChat side as Grafana 5.2.1 can send to slack fine but when switching to a rocketchat webhook-url the error occures.

FTR: I'm running rocket chat v0.66.3

thereapman on 20 Jul 2018

👍3

As a temporary workaround, you can use a manually applied script:

class Script {

    process_incoming_request({ request }) {

        request.content.attachments.forEach(function (attachment) {
            attachment.fields.forEach(function (field) {
                field.value = field.value.toString();
            });
        });

        return request;

    }
}

makubi on 24 Jul 2018

👍4 ❤1 🎉1

@RocketChat/core any idea why this workaround would be needed? :top:

It seems our webhook is not 100% slack compatible. Can we do something like the above workaround in our webhook to maintain slack compatible?

@makubi thanks for posting your workaround. I personally have needed this also :)

geekgonecrazy on 24 Jul 2018

From my tests the reason is Grafana doesn't send the text field and seems that we require it.

so the fix would be making text field optional.

sampaiodiego on 27 Jul 2018

❤1

Are you sure? @APenketh's log output says

Jul 19 14:28:45 rocketchat: error: 'Match error: Match error: Expected string, got number in field value' } }

and the workaround just converts the value value of all fields to Strings.

makubi on 1 Aug 2018

https://github.com/RocketChat/Rocket.Chat/blob/develop/packages/rocketchat-lib/server/functions/sendMessage.js#L25 looks like this line right here forces the field value to be a string.

@sampaiodiego should we make it any? or is there a way with check to make it anything but array or object? :no_mouth:

geekgonecrazy on 3 Aug 2018

Went ahead and opened a PR. I assume string and ints are the only real values that should be here.

_maybe_ bools?

geekgonecrazy on 10 Aug 2018

Hi,
currently running on 0.70.0, some of my grafana notifications are not received (I receive them via Email and via rocket-chat (via the slack notification channel), and sometimes the notifications are only received per Email)
I could not find anything in the logs from the administration page, (log level of 1). I just switched to 2.

Any hints how I could debug? / what file to look at ?

Many thanks !
François
