Exoplayer: Overflow of playerView in Viewpager

[EscapeArtist]

Content description

I have an activity set up with a Viewpager.
The Viewpager uses an adapter that creates Views( not fragments ).
Some of these views contain a PlayerView.
It all works perfectly fine unless I set the resizeMode to ZOOM.
When the resizeMode

is set to ZOOM, the playerView overflows onto the next / previous item in the Viewpager.
I have tried forcing the width to a set value, tried to force clipping to the parent, but to no avail.
I have tried setting the resize mode from both the xml directly and the view in code.
I have also tried playing with the player's videoScalingMode to C.VIDEO_SCALING_MODE_SCALE_TO_FIT_WITH_CROPPING but the issue is always there.
Here is a gif showing the issue. Here the Viewpager starts with a video that doesn't have ZOOM enabled, but the previous item in the Viewpager has ZOOM and is seen overflowing into the current item.

Link to test content

The videos are basic videos shot from iphones

Version of ExoPlayer being used

Using Exoplayer-core and -ui v2.9.6

Device(s) and version(s) of Android being used

Tested on various phones, all reproduce errors. Min SDK is set to 22.

[google-oss-bot]

This issue does not seem to follow the issue template. Make sure you provide all the required information.

[andrewlewis]

I tried to reproduce this by setting app:resize_mode="zoom" on a player view but the contents were clipped as expected. This Stack Overflow question covers the opposite problem so I wonder if it provides any clues to what's going on. If you think this is an ExoPlayer issue after investigating please provide a link to a minimal project that reproduces the issue and we can take a look.

[EscapeArtist]

the Viewpager is filled with other views like images, and even some exploayer not set to zoom, as you can see in the gif above.
All these things are clipped as expected. The only issue is when there's an exoplayer AND it is set to zoom.
That stackoverflow example assumes that by default everything is clipped properly, which agian is the case, even with the exoplayer NOT set in zoom.
It's the zoom setting that starts messing with the overflow.

[andrewlewis]

Please could you share a minimal demo project we can use to reproduce this? Thanks.

[EscapeArtist]

I have managed to reproduce the error pretty easily with a simple project.
The error happens when there is already an exoplayer in the current viewpager. The ZOOMed played from the next screen will then overflow and mix up with the surfaceview of the currently visible player.
Here is a zip file of a simple project where the error occurs.

ExoplayerOverflow.zip

[stephenBC]

You can use videoScalingMode = C.VIDEO_SCALING_MODE_SCALE_TO_FIT_WITH_CROPPING and resizeMode = AspectRatioFrameLayout.RESIZE_MODE_FILL.

Unfortunately there is also an issue with that solution when swiping, the aspect ratio gets changed like it is ignoring the scaling mode.

[malwinder-s]

I managed to fix this by adding this:

    <com.google.android.exoplayer2.ui.PlayerView
        app:resize_mode="zoom"
        app:surface_type="texture_view"
        ...
     />

[stephenBC]

@malwinder-s looks like that fixes it, thanks!

[EscapeArtist]

Seems to do the trick for me too, thanks.

[andrewlewis]

Thanks for the information. Closing as using TextureView instead of SurfaceView seems to work. See also Choosing a surface type.

[vindhyapratap]

app:surface_type="texture_view" this worked for me for black screen issue thanks a lot
