Core: Automation in UI throws: Message malformed: Integration ‘’ not found`

Created on 24 Mar 2020 · 13Comments · Source: home-assistant/core

The problem

Automations throws different errors when using UI.

Automation in UI throws: Message malformed: Integration not found

Tried with empty automation.yaml and new core.restore.state file, getting

Error processing the query: Unable to parse utterance. when trying to create a new automation.

Environment

Home Assistant release with the issue: 0.107.5
Last working Home Assistant release (if known): ?
Operating environment (Hass.io/Docker/Windows/etc.): Hassio/Docker/Ubuntu
Integration causing this issue: Automation
Link to integration documentation on our website:

Problem-relevant `automations.yaml`

```Can the problem be a mix of UI configured and old yaml configured ? Here is whole automations.yaml.

alias: Sol ned
trigger:
- platform: sun

  event: sunset

  offset: -00:20:00

  action:
- service: homeassistant.turn_on

  entity_id: light.trapp_ute,light.bod_ute

  data:

  brightness: 70
- service: homeassistant.turn_on

  entity_id: light.hue_white_lamp_1

  data:

  brightness: 150

  id: 2ee36c3f5c5f49f28e8b77b7f2e32913
alias: Sol opp
trigger:
- platform: sun

  event: sunrise

  action:
- service: homeassistant.turn_off

  entity_id: light.trapp_ute
- service: homeassistant.turn_off

  entity_id: light.bod_ute
- service: homeassistant.turn_off

  entity_id: light.hue_white_lamp_1

  id: bbabba7a32ae4ff481f30116b4bcb5d8
alias: Bod ute av
trigger:
- platform: time

  at: '22:30'

  action:
- service: homeassistant.turn_off

  entity_id: light.bod_ute

  id: 0bd485caeb9c4692a911c02d935590fe
alias: Lys Av
trigger:
- platform: time

  at: '23:30'

  action:
- service: homeassistant.turn_off

  entity_id: light.stue,light.kjokken,light.lampe_mellomgang
- service: homeassistant.turn_off

  entity_id: switch.stor_lampe_stue,switch.stue_lampe_stor_vindu

  id: 9c1d5ad60fa149a08a0d1cd7dce942ef
alias: Lys
trigger:
- platform: state

  entity_id: device_tracker._ios

  from: not_home

  to: home
- platform: sun

  event: sunset

  condition:

  condition: and

  conditions:
- condition: sun

  after: sunset

  after_offset: -00:20:00
- condition: time

  before: '22:00:00'
- condition: state

  entity_id: device_tracker._ios

  state: home

  action:
- service: homeassistant.turn_on

  entity_id: switch.stor_lampe_stue,switch.stue_lampe_stor_vindu
- service: homeassistant.turn_on

  entity_id: light.stue,light.kjokken

  data:

  brightness: 115
- service: homeassistant.turn_on

  entity_id: light.lampe_mellomgang

  data:

  brightness: 70
- service: homeassistant.turn_on

  entity_id: light.ute

  data:

  brightness: 30

  id: 5178ba18fed5419793f22fd18af7525e
alias: Lys
trigger:
- platform: state

  entity_id: device_tracker._ios

  from: not_home

  to: home
- platform: sun

  event: sunset

  condition:

  condition: and

  conditions:
- condition: sun

  after: sunset

  after_offset: -00:20:00
- condition: time

  before: '22:00:00'
- condition: state

  entity_id: device_tracker._ios

  state: home

  action:
- service: homeassistant.turn_on

  entity_id: switch.stor_lampe_stue,switch.stue_lampe_stor_vindu
- service: homeassistant.turn_on

  entity_id: light.stue,light.kjokken

  data:

  brightness: 115
- service: homeassistant.turn_on

  entity_id: light.lampe_mellomgang

  data:

  brightness: 70
- service: homeassistant.turn_on

  entity_id: light.ute

  data:

  brightness: 30

  id: a3c16d3fd45147b996d60173ced3235b
alias: Lys
trigger:
- platform: state

  entity_id: device_tracker._android

  from: not_home

  to: home
- platform: sun

  event: sunset

  condition:

  condition: and

  conditions:
- condition: sun

  after: sunset

  after_offset: -00:20:00
- condition: time

  before: '22:00:00'
- condition: state

  entity_id: device_tracker._android

  state: home

  action:
- service: homeassistant.turn_on

  entity_id: switch.stor_lampe_stue,switch.stue_lampe_stor_vindu
- service: homeassistant.turn_on

  entity_id: light.stue,light.kjokken

  data:

  brightness: 115
- service: homeassistant.turn_on

  entity_id: light.lampe_mellomgang

  data:

  brightness: 70
- service: homeassistant.turn_on

  entity_id: light.ute

  data:

  brightness: 30

  id: 46462ea53161463ea1fa57ec733589f2
alias: Lys
trigger:
- platform: state

  entity_id: device_tracker_ios

  from: not_home

  to: home
- platform: sun

  event: sunset

  condition:

  condition: and

  conditions:
- condition: sun

  after: sunset

  after_offset: -00:20:00
- condition: time

  before: '22:00:00'
- condition: state

  entity_id: device_tracker._ios

  state: home

  action:
- service: homeassistant.turn_on

  entity_id: switch.stor_lampe_stue,switch.stue_lampe_stor_vindu
- service: homeassistant.turn_on

  entity_id: light.stue,light.kjokken

  data:

  brightness: 115
- service: homeassistant.turn_on

  entity_id: light.lampe_mellomgang

  data:

  brightness: 70
- service: homeassistant.turn_on

  entity_id: light.ute

  data:

  brightness: 30

  id: 25e7d43b0b704184bb74dad42397fcba
id: '1584957937348'
alias: Varmeovn kjellerstue on
description: ''
trigger:
- entity_id: sensor.netatmo_hoyby_inne_temperature

  platform: state

  condition:
- below: '19'

  condition: numeric_state

  entity_id: sensor.netatmo_hoyby_inne_temperature
- after: 09:00

  before: '21:00'

  condition: time

  action:
- device_id: e53f47a963e44006bd7309abf0f319d5

  domain: light

  entity_id: light.hue_smart_plug_1

  type: turn_on
id: '1584958827766'
alias: Varmeovn kjeller off
description: ''
trigger:
- entity_id: sensor.netatmo_hoyby_inne_temperature

  platform: state

  condition:
- above: '19.5'

  condition: numeric_state

  entity_id: sensor.netatmo_hoyby_inne_temperature

  action:
- device_id: e53f47a963e44006bd7309abf0f319d5

  domain: light

  entity_id: light.hue_smart_plug_1

  type: turn_off

Also happends with empty automations.yaml file.

## Traceback/Error logs
<!--
  If you come across any trace or error logs, please provide them.
-->



```txt
No traceback found.
Error Message malformed: Integration ‘’ not found

Additional information

Example is from user fermulator, that also has the problem.
The predefined automations work.

Example, I created this automation:

Copy to clipboard

id: '1584962954826'
alias: Energy Savings (TOU off-peak)
description: Only ON during off-peak (7PM -> 7AM)
trigger:
- at: 07:00:00

  platform: time

  condition: []

  action:
- scene: scene.energy_savings_tou_off_peak

  based off this scene:

Copy to clipboard

id: '1584962996368'
name: Energy Savings (TOU off-peak)
entities: {}
That all worked.

However trying to create a similar one in the UI same naming chars etc, and it doesn’t work!

Copy to clipboard
Name: Energy Savings (TOU winter on-peak morning)
Desc: OFF (7AM -> 11AM)
Active Scene: scene.energy_savings_tou_on_peak_winter
save button doesn’t work, then it says at the top in red:

Message malformed: Integration ‘’ not found

auto1
auto2

automation

Source

jonare77

👍5

Most helpful comment

(go away bot)

fermulator on 25 Jul 2020

😄2

All 13 comments

Hey there @home-assistant/core, mind taking a look at this issue as its been labeled with a integration (automation) you are listed as a codeowner for? Thanks!

probot-home-assistant[bot] on 24 Mar 2020

I recently upgraded from 105 to 107, also hitting this issue.

note initially piggy-backed on https://community.home-assistant.io/t/message-malformed-integration-not-found-what-have-i-done/178480/19

fermulator on 24 Mar 2020

👍1

HA 0.107.7 , Python virtual environment, same issue.
Restart helped.
Unfortunately, immediately rebooted, did not guess to collect the details...

Magalex2x14 on 1 Apr 2020

i was just getting this same issue when attempting to add an automation.

in my case, it was because the empty "condition" was being sent. after deleting the empty default condition it let me save.

here is what was being sent upon clicking save:

{
   "description" : "",
   "alias" : "lamp (refresh)",
   "condition" : [
      {
         "device_id" : "",
         "entity_id" : "",
         "domain" : "",
         "condition" : "device"
      }
   ],
   "action" : [
      {
         "service" : "zwave.refresh_entity",
         "entity_id" : "zwave.aeon_labs_dsc06106_smart_energy_switch_3",
         "data" : {}
      }
   ],
   "trigger" : [
      {
         "domain" : "switch",
         "entity_id" : "switch.aeon_labs_dsc06106_smart_energy_switch_switch",
         "device_id" : "b8ba24d3847b4f0e98b6a915ece6f761",
         "type" : "turned_on",
         "platform" : "device"
      },
      {
         "domain" : "switch",
         "device_id" : "b8ba24d3847b4f0e98b6a915ece6f761",
         "type" : "turned_off",
         "platform" : "device",
         "entity_id" : "switch.aeon_labs_dsc06106_smart_energy_switch_switch"
      }
   ]
}

and the response:

{"message": "Message malformed: Integration '' not found"}

not sure if this is the same things the other people have mentioned, but maybe it will help someone.

tofurky on 22 Apr 2020

confirmed, the recent UI creations created like this in the yaml

- id: '1582060426859'
  alias: Energy Savings (blah)
  description: snip
  trigger:
  - at: '20:30:00'
    platform: time
  - at: 07:00:00
    platform: time
  condition: []                            <<<<<<<<<<<<<<<<< this?
  action:
  - entity_id: switch.leviton_dzpa1_2bw_plug_in_outlet_switch
    service: switch.toggle

fermulator on 22 Apr 2020

There hasn't been any activity on this issue recently. Due to the high number of incoming GitHub notifications, we have to clean some of the old issues, as many of them have already been resolved with the latest updates.
Please make sure to update to the latest Home Assistant version and check if that solves the issue. Let us know if that works for you by adding a comment 👍
This issue now has been marked as stale and will be closed if no further activity occurs. Thank you for your contributions.
