Azure-docs: CREATE SERVER AUDIT on Managed Instance

[mferris2421]

The code provided with RETENTION DAYS specified throws error stating syntax is incorrect.

---

Document Details

⚠ Do not edit this section. It is required for docs.microsoft.com ➟ GitHub issue linking.

• ID: a258bb07-e71a-d4e1-5f2c-bdad60a6a2e1
• Version Independent ID: 9bf5c440-3231-96be-e6ff-548e686c0203
• Content: Azure SQL Database Managed Instance Auditing
• Content Source: articles/sql-database/sql-database-managed-instance-auditing.md
• Service: sql-database
• GitHub Login: @giladm
• Microsoft Alias: giladm

[Mike-Ubezzi-MSFT]

@mferris2421 I am seeing the same exception. Just to confirm, are you running Azure SQL database Managed Instance? I am unable to complete the CREATE CREDENTIAL T-SQL because I am using Azure SQL Database and this command is not supported. I am not using Managed Instance.

But I am seeing the retention days error:

Msg 102, Level 15, State 1, Line 7 Incorrect syntax near ', RETENTION_DAYS = 10 '.

I do not have access to Azure SQL Database Managed Instance to verify if this syntax is correct or not.

[Mike-Ubezzi-MSFT]

@giladmit Can you confirm if the SQL syntax is correct for step 6 in this tutorial: Set up auditing for your server Thank you, Mike

[mferris2421]

@Mike-Ubezzi-MSFT Correct, I am using the syntax provided in the doc, against a Managed Instance preview.

I was able to create a server audit without the retention parameter.

CREATE SERVER AUDIT [x_audit]
TO URL (PATH ='https://x.core.windows.net/x/')
GO

Now when I try to start the audit, I get an error:

ALTER SERVER AUDIT [x_audit]
WITH (STATE=ON);
GO

[giladmit]

There seem to be two different issues here:

1. In Mike's T-SQL statement, the brackets around the ", RETENTION_DAYS=10" part of the statement should be removed (in the statement definition, they denote that this is an optional parameter).
2. In Matt's T-SQL, there's an error in the container URL PATH, it's missing the "blob" part - should be 'https://x.blob.core.windows.net/x' (not 'https://x.core.windows.net/x/')

Thanks,
Gilad (MSFT)

[mferris2421]

@giladmit Sorry, that was me trying to sanitize the statement. I deleted too much. My command included the correct address.

Regarding the integer example, thank you for pointing that out. I'm not familiar with T-SQL or even SQL admittedly, and I took the brackets are part of the syntax. I was able to successfully alter my server audit without the brackets. Thanks!

I still have the same problem starting my audit.

ALTER SERVER AUDIT [X_audit]
WITH (STATE=ON);
GO

Msg 33222, Level 16, State 1, Line 1
Audit 'DOTAZMSQLT1_audit' failed to start

[giladmit]

@mferris2421, no problem, thanks for clarifying.

We're looking into it. In the meantime, can you tell me if you created new credentials for that container?

Thanks,
Gilad (MSFT)

[mferris2421]

@giladmit, Correct I was able to create new credentials to my blob storage.

CREATE CREDENTIAL [https://x.blob.core.windows.net/x]
WITH IDENTITY='SHARED ACCESS SIGNATURE',
SECRET = 'mykey'
GO

[mferris2421]

@giladmit

Just following up on this one. So far, we're still just piloting things and figured out our issue; but this would be good to know for the future.

[CarlRabeler]

please-close as resolved

[Mike-Ubezzi-MSFT]

@mferris2421 We will now proceed to close this thread. If there are further questions regarding this matter, please reopen it and we will gladly continue the discussion.

[saurabhsuman38]

What was the solution to the problem?

[ikflc]

Hi Mike,
Can you please let me know the solution to it? I am hitting the same issue.
I raised a MS support call but is taking long.

CREATE CREDENTIAL [https://xxx/yyy-aud]
WITH IDENTITY='SHARED ACCESS SIGNATURE',
SECRET = 'key without ? from the beginning of the token'
GO

CREATE SERVER AUDIT [SQLMI_SVRAUD]
TO URL ( PATH ='https://xxx/yyy-aud' , RETENTION_DAYS = 7 )
GO

alter server audit [SQLMI_SVRAUD]
with (STATE=ON)
go

Msg 33222, Level 16, State 1, Line 10
Audit 'SQLMI_SVRAUD' failed to start . For more information, see the SQL Server error log. You can also query sys.dm_os_ring_buffers where ring_buffer_type = 'RING_BUFFER_XE_LOG'.

Thanks & regards,
Irene

[Mike-Ubezzi-MSFT]

@ikflc Can you provide me the support request ID, as I need to include this in the escalation I am going to send out. Thank you!
P.S. You can include it here or send to me via AzCommunity email.

[Mike-Ubezzi-MSFT]

Can you also include the following out from: For more information, see the SQL Server error log. You can also query sys.dm_os_ring_buffers where ring_buffer_type = 'RING_BUFFER_XE_LOG'

[ikflc]

Hi There,

Support Id 120012223000709

I got the following by running
select * from sys.dm_os_ring_buffers where ring_buffer_type = 'RING_BUFFER_XE_LOG'

We are now looking to see if it is a networking permission issue.

Thanks & regards,
Irene

[Mike-Ubezzi-MSFT]

@ikflc You can also do the following to get more helpful information:

I believe you might get some more information by looking at the SQL Error logs rather than the xevent ring buffers. Try the following:

"Open SSMS > Connect to the SQLMI instance > expand and browse to the Management > SQL Server Logs > Current Log"
Once you have the current log open, try restarting the Audit then refresh the log, and there should be a more verbose / text-based entry in there that will likely be more helpful.

If you need help translating or understanding the error, I can assist.

[Mike-Ubezzi-MSFT]

@ikflc Wanted to follow-up and see if you were able to resolve this? Per the support request that was opened for this specific issue, the following is the issue:

It seems that access to storage account is restricted to MI VNet, which requires service endpoint. It in turn requires subnet delegation turned on on MI subnet - which is not done.

[ikflc]

Hi Mike,
I am still waiting for our cloud team to action. I think the issue can be closed.
Thanks for your follow-up.
Best regards,
Irene

From: Mike Ubezzi [e-mail]
Sent: Thursday, 30 January 2020 10:32 AM
To: MicrosoftDocs/azure-docs [e-mail]
Cc: Irene Lam [e-mail]; Mention [e-mail]
Subject: Re: [MicrosoftDocs/azure-docs] CREATE SERVER AUDIT on Managed Instance (#8416)

@ikflchttps://urldefense.com/v3/__https:/github.com/ikflc__;!!HKeyBm8!CQU5z2F86KKYt8Du_uOV0djSTgQvrvur2axDIl5IEajdqe_WGzjgSlFpfT3bQJw$ Wanted to follow-up and see if you were able to resolve this? Per the support request that was opened for this specific issue, the following is the issue:

It seems that access to storage account is restricted to MI VNet, which requires service endpoint. It in turn requires subnet delegation turned on on MI subnet - which is not done.

—
